B4J Code Snippet Add a ToolTip to an ImageView

Discussion in 'B4J Code Snippets' started by rwblinn, Apr 5, 2016.

  1. rwblinn

    rwblinn Well-Known Member Licensed User

    Hi,

    this small code snippet adds a ToolTipText to an ImageView - as currently not exposed.

    Code:
    'Add a tooltip to an ImageView
    'JavaFX API Reference: http://download.java.net/jdk8/jfxdocs/javafx/scene/control/Tooltip.html
    Sub ToolTipToImageView(iv As ImageView, msg As String)

    Dim joToolTip As JavaObject

    Dim joToolTip2 As JavaObject = joToolTip.InitializeNewInstance("javafx.scene.control.Tooltip"Array(msg))
        joToolTip.RunMethod(
    "install"Array(iv, joToolTip2))
    End Sub
    Example:
    Code:
    Private imgTMP36 As ImageView
    ToolTipToImageView(imgTMP36,
    "The TMP36 temperature sensor")

  2. Cableguy

    Cableguy Expert Licensed User

    Made a very small change to allow removing the tooltip .

    Code:
    private Sub ToolTipToImageView(iv As ImageView, msg As String, add As Boolean)

    Dim joToolTip As JavaObject

    Dim joToolTip2 As JavaObject = joToolTip.InitializeNewInstance("javafx.scene.control.Tooltip"Array(msg))

    If add = True Then
            joToolTip.RunMethod(
    "install"Array(iv, joToolTip2))

    Else
            joToolTip.RunMethod(
    "uninstall"Array(iv, joToolTip2))

    End If
    End Sub

    Last edited: Oct 27, 2016
    Mashiane and rwblinn like this.
  3. LucaMs

    LucaMs Expert Licensed User

    Why on ImageViews only? So it works on any Node (and View).

    Code:
    Private Sub ToolTipOnNode(Nd As Node, msg As String, add As Boolean)

    Dim joToolTip As JavaObject

    Dim joToolTip2 As JavaObject = joToolTip.InitializeNewInstance("javafx.scene.control.Tooltip"Array(msg))

    If add = True Then
            joToolTip.RunMethod(
    "install"Array(Nd, joToolTip2))

    Else
            joToolTip.RunMethod(
    "uninstall"Array(Nd, joToolTip2))

    End If
    End Sub

  4. LucaMs

    LucaMs Expert Licensed User

    Another version:
    Code:
    Private Sub ToolTipOnNode(Nd As Node, msg As String, fnt As Font, iv As ImageView, add As Boolean)

    Dim joToolTip As JavaObject

    Dim joToolTip2 As JavaObject = joToolTip.InitializeNewInstance("javafx.scene.control.Tooltip"Array(msg))

    If add = True Then
           joToolTip.RunMethod(
    "install"Array(Nd, joToolTip2))


    If fnt.IsInitialized Then
               joToolTip2.RunMethod(
    "setFont"Array(fnt))

    End If


    If iv.IsInitialized Then
               joToolTip2.RunMethod(
    "setGraphic"Array(iv))
               iv.Visible =
    True

    End If

    Else
           joToolTip.RunMethod(
    "uninstall"Array(Nd, joToolTip2))

    End If

    End Sub

    Erel likes this.
