Android Question Box2D world scale

Discussion in 'Android Questions' started by coldteam, Feb 25, 2018.

  1. coldteam

    coldteam Member Licensed User

    Hi,
    i try to start use Box2D and need some help:

    1. set camera like this:
    Code:
    Dim Scale As Int = 100
    Sub LG_Resize(Width As Int, Height As Int)

    Camera.Initialize2( Scale * 4, Scale * 4 * Height / Width)

    Camera.Position.set(0, Scale, 0)
    End Sub
    2. set world:
    Code:
    Dim vGravity As lgMathVector2
        World.Initialize(vGravity.set(
    0, -300), True"World")
        World.SetContinuousPhysics(
    True)
        World.SetWarmStarting(
    True)
    3. create ground:
    Code:
    Dim bd As lgBox2DBodyDef

    Dim ground As lgBox2DBody = World.createBody(bd)

    Dim edgShape As lgBox2DEdgeShape

    Dim V1, V2 As lgMathVector2
        edgShape.set(V1.set(-
    1900), V2.set(1900))
        ground.createFixture2(edgShape,
    0)
        edgShape.dispose
    4. create Dynamic body
    Code:
    Dim circle As lgBox2DCircleShape

    circle.Radius = 10

    Dim circleShapeDef As lgBox2DFixtureDef
        circleShapeDef.shape =
    circle
        circleShapeDef.Density =
    1
        circleShapeDef.restitution =
    0.2

    Dim circleBodyDef As lgBox2DBodyDef
        circleBodyDef.Type = World.BODYTYPE_Dynamic
        circleBodyDef.position.set(
    0100)
        CI = World.createBody(circleBodyDef)
        CI.createFixture(circleShapeDef)

    circle.dispose
    5. try applyLinearImpulse Y
    Code:
    CI.applyLinearImpulse2(0,100000,CI.WorldCenter.x,CI.WorldCenter.y,True)
    6. add text
    Code:
    bitfont = FG.CreateFont("font1.ttf"10dip,"TEX")
    Dim Str As String = "TEXT"
        bitfont.Draw(Batch, Str,
    Camera.Position.x-(bitfont.GetBounds(Str).Width/2),Camera.Position.y+(bitfont.GetBounds(Str).Height/2))
    I wanted it to look the same on different screens

    questions:
    - what am I doing wrong?
    - body is very large?(falls slowly)

    if i do Scale = 10 its ok, but i cant draw bitmapfont(rly big)
    - very large pulse value, is it ok ?


    Attached Files:

    • rrr.png
      File size:
      4.4 KB
      Views:
      149
  2. coldteam

    coldteam Member Licensed User

    i try

    Code:
    scale = 50
    bitfont = FG.CreateFont(
    "font2.ttf",10*Density"0123456789.,")
    but it looks bad


    Attached Files:

  3. Eme Fibonacci

    Eme Fibonacci Well-Known Member Licensed User

    I am not an expert but I already did some things with Box2d.

    You should think about Box2D as a world in meters.

    You must understand that there is a difference between LibGDX and Box2d.

    See tutorials on youtube about Box2D coordinate system

    coldteam likes this.
  4. coldteam

    coldteam Member Licensed User

    Thank you,
    Yes, I understand that.
    I created scale, and reduced camera view
    but if the pixel world is so small
    how to draw a font?

  5. Eme Fibonacci

    Eme Fibonacci Well-Known Member Licensed User

    camera positions and screen positions are different things.
    Tomorrow I'll post a small example.

    coldteam likes this.
  6. coldteam

    coldteam Member Licensed User

    nice, link me pls

  7. coldteam

    coldteam Member Licensed User

  8. Eme Fibonacci

    Eme Fibonacci Well-Known Member Licensed User

    Today I will check a small example that I made and put here. Please wait.

  9. Eme Fibonacci

    Eme Fibonacci Well-Known Member Licensed User

    Again. I am not an expert and there must be better ways of doing this.
    I hope this is helpful

    Code:
    Sub Process_Globals
    End Sub

    Sub Globals


    Dim lGdx As LibGDX

    Dim GL As lgGL

    Dim Camera, CameraFont As lgOrthographicCamera

    Dim World As lgBox2DWorld

    Dim Renderer As lgBox2DDebugRenderer

    Dim LG_Batch As lgSpriteBatch

    Dim Font As lgBitmapFont

    End Sub

    Sub Activity_Create(FirstTime As Boolean)
        lGdx.Initialize(
    "LG")
    End Sub

    Sub LG_Create


    'Initializes the sprite batcher
        LG_Batch.Initialize


    'Font
        Font.Initialize

    Font.SetColorRGBA(1,0,0,1)

    Font.Scale(Density*2)


    'Debug renderer
        Renderer.Initialize2(TrueFalseFalseTrueTrueTrue)


    'World
        Dim vGravity As lgMathVector2
        World.Initialize(vGravity.set(
    0, -10), True"Box2D")
        World.SetContinuousPhysics(
    True)
        World.SetWarmStarting(
    True)


    'I create objects (floor 2.8x0.5 meters)
        'Floor
        Dim fd As lgBox2DFixtureDef

    Dim sd As lgBox2DPolygonShape
        sd.setAsBox(
    1.4,.25)
        fd.shape = sd

    Dim bd As lgBox2DBodyDef
        bd.position.set(
    1.5,.25)
        World.createBody(bd).createFixture(fd)
        sd.1dispose

    'Box (2x2 meters)
        Dim fd As lgBox2DFixtureDef

    Dim sd As lgBox2DPolygonShape
        sd.setAsBox(
    1,1)
        fd.shape = sd

    Dim bd As lgBox2DBodyDef
        bd.position.set(
    1.5,4.5)
        bd.type=World.BODYTYPE_Dynamic
        World.createBody(bd).createFixture(fd)
        sd.dispose

    End Sub

    Sub LG_Resize(Width As Int, Height As Int)

    'In my example I create a 3x5 camera
        Camera.Initialize2(35)

    Camera.Position.set(1.5,2.5,0)


    'I create a second camera with actual size of the device. In this camera I draw the text.
        'Set CameraFont
        CameraFont.Initialize2(lGdx.Graphics.Width,lGdx.Graphics.Height)
        CameraFont.Position.set(lGdx.Graphics.Width/
    2,lGdx.Graphics.Height/2,0)

    End Sub

    Sub LG_Render


    'Clears the screen
        GL.glClear(GL.GL10_COLOR_BUFFER_BIT)


    'Updates the matrices of the cameras
        Camera.Update


    'Updates and draws the simulation
        LG_Update
        Renderer.render(World.InternalObject,
    Camera.Combined)


    'Font
        CameraFont.Update
        LG_Batch.ProjectionMatrix = CameraFont.Combined
        LG_Batch.begin

    Font.Draw(LG_Batch,"B4A",lGdx.Graphics.Width*.25,lGdx.Graphics.Height*.75)
        LG_Batch.end

    End Sub

    Sub LG_Update
        World.Step(
    1/6083)
    End Sub

    Sub LG_Dispose


    'Disposes all resources
        Renderer.dispose
        World.dispose

    End Sub

    Last edited: Mar 3, 2018
    coldteam likes this.
  10. coldteam

    coldteam Member Licensed User

    Hello, Thank you!
    it works, but Informatix
    write "A SpriteBatch is a pretty heavy object so you should only ever have one in your program."
    and if i already use "
    lgMapOrthogonalTiledMapRenderer"
    With "Renderer.SpriteBatch"
    I mean, is this normal?

    Last edited: Mar 3, 2018
  11. Eme Fibonacci

    Eme Fibonacci Well-Known Member Licensed User

    I agree but you could have only one object SpriteBatch
    Adjusted two times. One for the sprites and another for the font.

    Code:
    LG_Batch.ProjectionMatrix = Camera.Combined
    'Draw Sprites
    ....
    LG_Batch.ProjectionMatrix = CameraFont.Combined
    'Draw Text
    Another solution is to adjust the coordinates and scale and use only one camera

    Last edited: Mar 3, 2018
