Filling image with color

[xamrex]

Hello.
How can I fill this bulb:

with a color?

My phone will be conected with microcontroller, and this bulb should shows color form RGB Diode.

How can I fill this bulb with color?



[klaus]

I don't think that there does exist a library for doing this.
It would be easier to load bitmaps with colored bulbs.
Or you could write your own routine.
If you want to fill a surface this one must have only one color.
Your bitmap seems not beeing 'clean' inside.

Best regards.



[xamrex]

It would be easier to load bitmaps with colored bulbs.

It is not possible. I would have to have 255*255*255 bitmaps;/

Your bitmap seems not beeing 'clean' inside.

I can clean this bitmap inside...


I thought about circle filled inside with color, but this circle does not look like a bulb;/



[klaus]

What you could try to do is to define a path of the contour of the bulb and fill it with the given color.

Best regards.



[xamrex]

Thanks,
Could you tell me what function I need to use to define contour?



[magicuser68]

You could use Photoshop or Gimp and make the part you want to fill with color transparent then save it in ".png" format? In your program create a panel and add your light bulb bitmap. To change the color of the bulb just change your background color of the panel.

FYI - Transparency is sometimes called alpha channel.


Update:
I edited your picture and added the alpha channel. I have attached it for you.

- Scott



[klaus]

Here you have an example of drawing with a Path. It would also need a bitmap with the bulb image and the internal part transparent like migicuser68s' proposal.
But migicuser68s' solution is simpler than mine.
But I post it anyway as an example.

Sub Process_Globals
    Dim Timer1 As Timer
End Sub

Sub Globals
    Dim pnlMain As Panel
    Dim cvsMain As Canvas
    Dim pthBulb As Path
End Sub

Sub Activity_Create(FirstTime As Boolean)
    pnlMain.Initialize("pnlMain")
    Activity.AddView(pnlMain, 50%x - 100dip, 50dip, 200dip, 300dip)
    pnlMain.Color = Colors.White

    cvsMain.Initialize(pnlMain)
    cvsMain.RemoveClip
    Timer1.Initialize("Timer1", 1000)
    Timer1.Enabled = True
End Sub

Sub Activity_Resume
    DefineBulbPath
    DrawBulb(Colors.Red)
End Sub

Sub Activity_Pause (UserClosed As Boolean)
    Timer1.Enabled = False
End Sub

Sub Timer1_Tick
    DrawBulb(Colors.RGB(Rnd(0,256), Rnd(0,256), Rnd(0,256)))
    pnlMain.Invalidate
End Sub

Sub DrawBulb(col As Int)
    cvsMain.DrawPath(pthBulb, col, True, 1)
End Sub

Sub DefineBulbPath
    Dim x0, y0 As Float

    x0 = pnlMain.Width / 2
    y0 = 20dip
    pthBulb.Initialize(x0, y0)
    pthBulb.LineTo(x0 + 20dip, y0 + 5dip)
    pthBulb.LineTo(x0 + 40dip, y0 + 10dip)
    pthBulb.LineTo(x0 + 60dip, y0 + 30dip)
    pthBulb.LineTo(x0 + 70dip, y0 + 50dip)
    pthBulb.LineTo(x0 + 70dip, y0 + 80dip)
    pthBulb.LineTo(x0 + 65dip, y0 + 100dip)
    pthBulb.LineTo(x0 + 55dip, y0 + 120dip)
    pthBulb.LineTo(x0 + 45dip, y0 + 150dip)
    pthBulb.LineTo(x0 + 40dip, y0 + 180dip)
    pthBulb.LineTo(x0 + 38dip, y0 + 186dip)
    pthBulb.LineTo(x0 + 32dip, y0 + 190dip)

    pthBulb.LineTo(x0 - 32dip, y0 + 190dip)
    pthBulb.LineTo(x0 - 38dip, y0 + 186dip)
    pthBulb.LineTo(x0 - 40dip, y0 + 180dip)
    pthBulb.LineTo(x0 - 45dip, y0 + 150dip)
    pthBulb.LineTo(x0 - 55dip, y0 + 120dip)
    pthBulb.LineTo(x0 - 65dip, y0 + 100dip)
    pthBulb.LineTo(x0 - 70dip, y0 + 80dip)
    pthBulb.LineTo(x0 - 70dip, y0 + 50dip)
    pthBulb.LineTo(x0 - 60dip, y0 + 30dip)
    pthBulb.LineTo(x0 - 40dip, y0 + 10dip)
    pthBulb.LineTo(x0 - 20dip, y0 + 5dip)
    pthBulb.LineTo(x0, y0)
End Sub

Best regards.



[xamrex]

thank you
