B4J Question Snapshot

[RobRock92]

Hi , I would like to know how to make the screen shot of the form and print it with printhtml tool, thanks



[Erel]

You should create a template file. It should point to the image:

<img src="image.png" />

Now in your code you should save the snapshot to this image and print the template:

Sub Process_Globals
   Private fx As JFX
   Private MainForm As Form
   Private sh As Shell
End Sub

Sub AppStart (Form1 As Form, Args() As String)
   MainForm = Form1
   MainForm.RootPane.LoadLayout("1") 'Load the layout file.
   MainForm.Show

End Sub
Sub Button1_Action
   Dim out As OutputStream = File.OpenOutput(File.DirApp, "image.png", False)
   MainForm.RootPane.Snapshot.WriteToStream(out)
   out.Close
   Dim params As List
   params.Initialize
   'params.Add("printername=novapdf")
   params.Add("file=template.html")
   sh.Initialize("sh", "printhtml.exe", params)
   sh.WorkingDirectory = File.DirApp
   sh.Run(-1)
End Sub

Sub sh_ProcessCompleted (Success As Boolean, ExitCode As Int, StdOut As String, StdErr As String)
   Log("Success=" & Success & ", StdOut=" & StdOut & ", StdErr=" & StdErr)
End Sub



[RobRock92]

You should create a template file. It should point to the image:

<img src="image.png" />

Now in your code you should save the snapshot to this image and print the template:

Sub Process_Globals
   Private fx As JFX
   Private MainForm As Form
   Private sh As Shell
End Sub

Sub AppStart (Form1 As Form, Args() As String)
   MainForm = Form1
   MainForm.RootPane.LoadLayout("1") 'Load the layout file.
   MainForm.Show

End Sub
Sub Button1_Action
   Dim out As OutputStream = File.OpenOutput(File.DirApp, "image.png", False)
   MainForm.RootPane.Snapshot.WriteToStream(out)
   out.Close
   Dim params As List
   params.Initialize
   'params.Add("printername=novapdf")
   params.Add("file=template.html")
   sh.Initialize("sh", "printhtml.exe", params)
   sh.WorkingDirectory = File.DirApp
   sh.Run(-1)
End Sub

Sub sh_ProcessCompleted (Success As Boolean, ExitCode As Int, StdOut As String, StdErr As String)
   Log("Success=" & Success & ", StdOut=" & StdOut & ", StdErr=" & StdErr)
End Sub

And how create a template file programmatically and delet it after print? thanks Erel



[Erel]

The template file is a standard html file. You can leave it as is if you want to print the image.

If you like you can use File.WriteText to build it programmatically.



[Theera]

Hi all,
I've error this,how to get rid of this. Assume I've added my picture at Files Tab already(my picture is bigger than permit posting.)

Program started.
Success=true, StdOut=HTMLPRINT 4.0.0.19 - Copyright 2013
Unable to load HTML from file 'template.html'. The file does not exist.
, StdErr=



[magoandroid]

Hi all,
I've error this,how to get rid of this. Assume I've added my picture at Files Tab already(my picture is bigger than permit posting.)

Hi Theera,
I looked your code.
Printhtml.exe expects to find the template file in the folder of the application (File.DirApp) where you save the file "ThaiHistory.png."
Your file "template.html" instead is located in the DirAssets.
Flip it and you'll see that it will work.

Greetings.
MAgo



[Theera]

Hi all,
In post#2,I think Erel forgot to add alike this code,doesn't he? as below:
File.ReadString(File.DirAssets,"template.html")
,but I cann't make it work.

P.S. I compared with Erel's print example.



[Theera]

Ok Work Now.

I use this code instead of the post#7

File.Copy(File.DirAssets,"template.html",File.DirApp,"template.html")



[RobRock92]

The template file is a standard html file. You can leave it as is if you want to print the image.

If you like you can use File.WriteText to build it programmatically.

Thanks Erel , it work
