Using jShell library we can get the laptop battery information as name, serial number, manufacturer, design and current capacity as well as charge remaining (taken from:https://www.b4x.com/android/forum/threads/execute-windows-vbs-scripts-from-b4j.73612/#content)
Example output:
B4X:
#Region Project Attributes
#MainFormWidth: 600
#MainFormHeight: 600
#End Region
Sub Process_Globals
Private fx As JFX
Private MainForm As Form
Private xui As XUI
Private Button1 As B4XView
Private ChargeRemaining As Int
End Sub
Sub AppStart (Form1 As Form, Args() As String)
MainForm = Form1
MainForm.RootPane.LoadLayout("Layout1")
'MainForm.Show
Dim shl As Shell
shl.Initialize("shl", "powercfg", _
Array As String("/batteryreport"))
shl.WorkingDirectory = "."
shl.Run(10000) 'set a timeout of 10 seconds
End Sub
Sub shl_ProcessCompleted (Success As Boolean, ExitCode As Int, StdOut As String, StdErr As String)
If Success And ExitCode = 0 Then
Log("Success")
Log("Full output: " & StdOut)
' Find the HTML file path in the output
Dim htmlFilePath As String = ExtractHtmlFilePath(StdOut)
If htmlFilePath <> "" Then
' Clean the path (remove trailing period if present)
If htmlFilePath.EndsWith(".") Then
htmlFilePath = htmlFilePath.SubString2(0, htmlFilePath.Length - 1)
End If
Log("HTML file path: " & htmlFilePath)
' Check if file exists
If File.Exists(htmlFilePath, "") Then
' Read the HTML file content
Dim html As String = File.ReadString(htmlFilePath, "")
ParseBatteryData(html)
Else
' Try alternative approach - search for battery-report.html in the Objects folder
htmlFilePath = FindBatteryReportFile
If htmlFilePath <> "" Then
Dim html As String = File.ReadString(htmlFilePath, "")
ParseBatteryData(html)
Else
Log("Could not find battery-report.html file")
xui.MsgboxAsync("Could not find battery report file", "Error")
End If
End If
Else
Log("Could not extract HTML file path from output")
' Try to generate the report to a specific location
GenerateBatteryReportToSpecificLocation
End If
Else
Log("Error: " & StdErr)
xui.MsgboxAsync("Failed to generate battery report: " & StdErr, "Error")
End If
'ExitApplication ' Optional - remove if you want app to continue
End Sub
Sub ExtractHtmlFilePath(output As String) As String
' Look for .html extension in the output
Dim pattern As String = "(C:\\.*?\.html)"
Dim matcher As Matcher = Regex.Matcher(pattern, output)
If matcher.Find Then
Return matcher.Group(1)
End If
' Alternative pattern for paths with spaces or special characters
Dim pattern2 As String = "(\w:.*?\.html)"
Dim matcher2 As Matcher = Regex.Matcher(pattern2, output)
If matcher2.Find Then
Return matcher2.Group(1)
End If
Return ""
End Sub
Sub FindBatteryReportFile As String
' Try to find the battery report file in common locations
Dim possiblePaths As List
possiblePaths.Initialize
' Add current directory
possiblePaths.Add(File.DirApp & "\battery-report.html")
' Try Objects folder (common in B4J projects)
possiblePaths.Add(File.DirApp & "\Objects\battery-report.html")
' Try user's documents folder
Dim j As JavaObject
j.InitializeStatic("java.lang.System")
Dim userHome As String = j.RunMethod("getProperty", Array As Object("user.home"))
possiblePaths.Add(userHome & "\battery-report.html")
For Each path As String In possiblePaths
If File.Exists(path, "") Then
Return path
End If
Next
Return ""
End Sub
Sub GenerateBatteryReportToSpecificLocation
' Generate battery report to a known location
Dim knownPath As String = File.DirApp & "\battery-report.html"
Dim shl2 As Shell
shl2.Initialize("shl2", "powercfg", Array As String("/batteryreport", "/output", knownPath))
shl2.WorkingDirectory = "."
shl2.Run(10000)
Wait For shl2_ProcessCompleted (Success As Boolean, ExitCode As Int, StdOut As String, StdErr As String)
If Success And ExitCode = 0 Then
If File.Exists(knownPath, "") Then
Dim html As String = File.ReadString(knownPath, "")
ParseBatteryData(html)
Else
xui.MsgboxAsync("Failed to generate battery report to known location", "Error")
End If
Else
xui.MsgboxAsync("Failed to generate battery report: " & StdErr, "Error")
End If
End Sub
Sub ParseBatteryData(html As String)
Try
''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''
''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''
' Parse for DESIGN CAPACITY - multiple possible patterns
Dim designCapacity As String = ""
Dim patterns As List
patterns.Initialize
' Try different possible patterns
patterns.Add("DESIGN CAPACITY</span></td><td>(\d+,\d+)\s*mWh")
patterns.Add("DESIGN CAPACITY[^>]*>(\d+,\d+)\s*mWh")
patterns.Add("DESIGN CAPACITY.*?<td[^>]*>(\d+,\d+)")
patterns.Add(">DESIGN CAPACITY<.*?<td[^>]*>(\d+,\d+)")
For Each pattern As String In patterns
Dim matcher As Matcher = Regex.Matcher(pattern, html)
If matcher.Find Then
designCapacity = matcher.Group(1)
Exit
End If
Next
' Parse for FULL CHARGE CAPACITY
Dim fullChargeCapacity As String = ""
Dim patterns2 As List
patterns2.Initialize
patterns2.Add("FULL CHARGE CAPACITY</span></td><td>(\d+,\d+)\s*mWh")
patterns2.Add("FULL CHARGE CAPACITY[^>]*>(\d+,\d+)\s*mWh")
patterns2.Add("FULL CHARGE CAPACITY.*?<td[^>]*>(\d+,\d+)")
patterns2.Add(">FULL CHARGE CAPACITY<.*?<td[^>]*>(\d+,\d+)")
For Each pattern As String In patterns2
Dim matcher As Matcher = Regex.Matcher(pattern, html)
If matcher.Find Then
fullChargeCapacity = matcher.Group(1)
Exit
End If
Next
If designCapacity <> "" And fullChargeCapacity <> "" Then
' Remove commas for calculation
Dim designClean As String = designCapacity.Replace(",", "")
Dim fullChargeClean As String = fullChargeCapacity.Replace(",", "")
' Convert to numbers
Dim designVal As Int = designClean
Dim fullChargeVal As Int = fullChargeClean
' Calculate battery health percentage
Dim health As Double = (fullChargeVal / designVal) * 100
' Display results
Log("Design Capacity: " & designCapacity & " mWh")
Log("Full Charge Capacity: " & fullChargeCapacity & " mWh")
Log("Battery Health: " & NumberFormat(health, 1, 2) & "%")
Log("Battery Manufacturer: " & ParseBatteryManufacturer(html))
Log("Serial Number:" & ParseBatterySerialNumber(html))
Log("Chemistry:" & ParseBatteryChemistry(html) )
' Show in a message box
xui.MsgboxAsync("Battery Status:" & CRLF & CRLF & _
"✓ Design Capacity: " & designCapacity & " mWh" & CRLF & _
"✓ Full Charge Capacity: " & fullChargeCapacity & " mWh" & CRLF & CRLF & _
"🔋 Battery Health: " & NumberFormat(health, 1, 2) & "%" & CRLF & CRLF & _
"Battery Name: " & ParseBatteryName(html) & CRLF & CRLF & _
"Battery Manufacturer: " & ParseBatteryManufacturer(html) & CRLF & CRLF & _
"Serial number: " & ParseBatterySerialNumber(html) & CRLF & CRLF & _
"Chemistry: " & ParseBatteryChemistry(html) , "Battery Report")
BatteryChargeRemain
Else
Log("Could not find battery capacity data in HTML")
Log("HTML snippet search:")
' Try a more aggressive search
FindCapacityValues(html)
End If
Catch
Log("Error parsing HTML: " & LastException)
xui.MsgboxAsync("Error parsing battery data", "Error")
End Try
End Sub
Sub FindCapacityValues(html As String)
' Alternative: Look for any numbers that look like capacities (typically in thousands)
Dim pattern As String = "(\d{1,3}(?:,\d{3})+)\s*mWh"
Dim matcher As Matcher = Regex.Matcher(pattern, html)
Dim matches As List
matches.Initialize
Do While matcher.Find
matches.Add(matcher.Group(1))
Loop
If matches.Size >= 2 Then
' Assume first two large numbers are the capacities
Dim designCapacity As String = matches.Get(0)
Dim fullChargeCapacity As String = matches.Get(1)
' Remove commas for calculation
Dim designClean As String = designCapacity.Replace(",", "")
Dim fullChargeClean As String = fullChargeCapacity.Replace(",", "")
Dim designVal As Int = designClean
Dim fullChargeVal As Int = fullChargeClean
Dim health As Double = (fullChargeVal / designVal) * 100
xui.MsgboxAsync("Battery Status (auto-detected):" & CRLF & CRLF & _
"Design Capacity: ~" & designCapacity & " mWh" & CRLF & _
"Full Charge Capacity: ~" & fullChargeCapacity & " mWh" & CRLF & CRLF & _
"Battery Health: ~" & NumberFormat(health, 1, 2) & "%", _
"Battery Report (Estimated)")
Else
' Last resort: Save HTML to file for debugging
File.WriteString(File.DirApp, "debug_battery.html", html)
Log("Could not parse data. HTML saved to: " & File.DirApp & "\debug_battery.html")
xui.MsgboxAsync("Could not parse battery data. Debug file created.", "Error")
End If
End Sub
Sub ParseBatteryName(html As String) As String
Dim namePatterns As List = Array As String($"NAME</span></td><td>([^<]+)"$, "Battery name.*?<td[^>]*>([^<]+)",">Name<.*?<td[^>]*>([^<]+)","Battery Name.*?:.*?<td>([^<]+)","<td>NAME</td>.*?<td>([^<]+)</td>",$"\"name\"[^>]*>([^<]+)"$)
For Each pattern As String In namePatterns
Dim matcher As Matcher = Regex.Matcher(pattern, html)
If matcher.Find Then
Dim name As String = matcher.Group(1).Trim
If name.Length > 0 Then
Return name
End If
End If
Next
Return "Unknown"
End Sub
Sub ParseBatteryManufacturer(html As String) As String
Dim manufacturerPatterns As List = Array As String("MANUFACTURER</span></td><td>([^<]+)","Manufacturer.*?<td[^>]*>([^<]+)",">Manufacturer<.*?<td[^>]*>([^<]+)","Battery manufacturer.*?:.*?<td>([^<]+)","<td>MANUFACTURER</td>.*?<td>([^<]+)</td>",$"\"manufacturer\"[^>]*>([^<]+)"$,"Mfg.*?:.*?<td>([^<]+)")
For Each pattern As String In manufacturerPatterns
Dim matcher As Matcher = Regex.Matcher(pattern, html)
If matcher.Find Then
Dim manufacturer As String = matcher.Group(1).Trim
If manufacturer.Length > 0 Then
Return manufacturer
End If
End If
Next
Return "Unknown"
End Sub
Sub ParseBatterySerialNumber(html As String) As String
Dim serialPatterns As List = Array As String("SERIAL NUMBER</span></td><td>([^<]+)","Serial.*?number.*?<td[^>]*>([^<]+)",">Serial number<.*?<td[^>]*>([^<]+)","Battery serial.*?:.*?<td>([^<]+)","<td>SERIAL NUMBER</td>.*?<td>([^<]+)</td>",$"\"serial.*?\"[^>]*>([^<]+)"$,$"SN.*?:.*?<td>([^<]+)"$,$"Serial.*?:.*?<td>([^<]+)"$)
For Each pattern As String In serialPatterns
Dim matcher As Matcher = Regex.Matcher(pattern, html)
If matcher.Find Then
Dim serial As String = matcher.Group(1).Trim
If serial.Length > 0 Then
Return serial
End If
End If
Next
Return "Unknown"
End Sub
Sub ParseBatteryChemistry(html As String) As String
Dim chemistryPatterns As List = Array As String("CHEMISTRY</span></td><td>([^<]+)","Chemistry.*?<td[^>]*>([^<]+)",">Chemistry<.*?<td[^>]*>([^<]+)","Battery chemistry.*?:.*?<td>([^<]+)","<td>CHEMISTRY</td>.*?<td>([^<]+)</td>",$"\"chemistry\"[^>]*>([^<]+)"$,"Battery type.*?:.*?<td>([^<]+)")
For Each pattern As String In chemistryPatterns
Dim matcher As Matcher = Regex.Matcher(pattern, html)
If matcher.Find Then
Dim chemistry As String = matcher.Group(1).Trim
If chemistry.Length > 0 Then
Return chemistry
End If
End If
Next
Return "Unknown"
End Sub
Sub ExtractAdditionalBatteryInfo(html As String) As String
Try
Dim info As String
' Extract battery cycles if available
Dim cyclePattern As String = "CYCLE COUNT</span></td><td>(\d+)"
Dim cycleMatcher As Matcher = Regex.Matcher(cyclePattern, html)
If cycleMatcher.Find Then
info= info & "Cycle Count: " & cycleMatcher.Group(1) & CRLF
End If
' Extract manufacture date if available
Dim datePattern As String = "MANUFACTURE DATE</span></td><td>([^<]+)"
Dim dateMatcher As Matcher = Regex.Matcher(datePattern, html)
If dateMatcher.Find Then
info= info & "Manufacture Date: " & dateMatcher.Group(1) & CRLF
End If
Catch
Log(LastException.Message)
' Ignore errors in additional info extraction
End Try
Return info
End Sub
Sub BatteryChargeRemain
Log("Reading battery status...")
Dim BatterySh As Shell
BatterySh.Initialize("Battery", "c:\windows\system32\cscript.exe", Array As String("//nologo", "battery.vbs"))
BatterySh.WorkingDirectory = "WinBattery\"
BatterySh.Run(10000)
End Sub
Sub Battery_ProcessCompleted (Success As Boolean, ExitCode As Int, StdOut As String, StdErr As String)
If Success And ExitCode = 0 Then
If IsNumber(StdOut) Then
ChargeRemaining= StdOut
Log ("Charge remainig: " & ChargeRemaining)
xui.MsgboxAsync(ChargeRemaining, "Charge Remaining")
Else
Log("Oops... Battery not found...")
End If
Else
Log("Error: " & StdErr & StdOut)
End If
End Sub
