Android Question Button Properties

[Duque]

Friends I need help, I created a panel which I add a few buttons per code but I can not find the properties for:
* Put an image on the button
* Know if pressed or not
* Round the top corners only



[ronell]

Put an image on the button

Dim bd As BitmapDrawable
    bd.Initialize(LoadBitmap(File.DirAssets,"yourpic.jpg"))

    Button1.Background = bd

Know if pressed or not

buttons must have the same event name

Sub Button_Click

    Dim btn As Button
    btn = Sender

    btn.Text = "click!"

End Sub



[Duque]

Thanks, it worked perfectly, it is possible to round off only the top corners, not all corners

example:

Corner radius (0,0,5,5)



[ronell]

Round the top corners only

you can use panels with an image of the shape you want and catch the click event in

Sub panel_Touch (Action As Int, X As Float, Y As Float) 'sample



[Duque]

'I have solved the click to the button and change the image with this function, as for rounding, you propose to create panels and use them as buttons?
code:

Sub estiloB2(b As Button)
'al clic
    Dim img1 As BitmapDrawable
     img1.Initialize(LoadBitmap(File.DirAssets,"ant.ico"))
'al soltar
    Dim img2 As BitmapDrawable
     img2.Initialize(LoadBitmap(File.DirAssets,"carg.ico"))

    Dim cambio As StateListDrawable
    cambio.Initialize
'al click
    Dim states(2) As Int
    states(0) = cambio.state_enabled
    states(1) = -cambio.state_pressed
    cambio.addState2(states, img1)
'al soltar
    Dim states(1) As Int
    states(0) = cambio.state_pressed
    cambio.addState2(states, img2)
    b.Background = cambio
End Sub



[ronell]



[Duque]

Thanks I noticed the newbie



[ronell]

create panels and use them as buttons?

Sub imgpanel_Touch (Action As Int, X As Float, Y As Float)
   Select Action
        Case Activity.ACTION_DOWN
                'this part is equivalent to _click event


        End Select
           End If
