B4J Question Size of PNG file created by Rootpane.SnapShot [SOLVED]

[aminoacid]

Hello All,
I am saving a snapshot of my form to a PNG file. The form is 1100 x 800 pixels and I have the following in my code:

#Region  Project Attributes
    #MainFormWidth: 1100
    #MainFormHeight: 800
#End Region

Sub AppStart (Form1 As Form, Args() As String)
    MainForm = Form1
    MainForm.RootPane.LoadLayout("1") 'Load the layout file.
    MainForm.WindowWidth = 1100
    MainForm.WindowHeight = 800
    MainForm.Resizable=False
    MainForm.Show
.
.
.

Then to take a a snapshot every minute, I use a timer with the following code:

Sub Timer3_tick
    Dim out As OutputStream = File.OpenOutput(File.DirApp, "temps.png", False)
    MainForm.RootPane.SetSize(1100,800)
    MainForm.RootPane.Snapshot.WriteToStream(out)
    out.Close
End Sub

The code works fine and the PNG file is created as expected. However the size of the PNG file is always 2000 x 1131 pixels when I expected it to be the size of the mainform which is 1100 x 800.

Is there any way to get it to create the PNG of the same size as the mainform?

Any pointers on this issue would be greatly appreciated as I have now tried almost everything to change the PNG size from 2000 x 1131 but nothing works.

Thanks!



[TILogistic]

Tested (lib XUI).

Sub Timer3_tick
    Dim out As OutputStream = File.OpenOutput(File.DirApp, "temps.png", False)
    Dim bmp As B4XBitmap = MainForm.RootPane.Snapshot
    bmp.Resize(1100, 800, False).WriteToStream(out,100,"PNG")
    out.Close
End Sub



[TILogistic]

With sub:

SnapShot(MainForm.RootPane)

Public Sub SnapShot (v As B4XView)
    Dim out As OutputStream = File.OpenOutput(File.DirApp, "temps.png", False)
    Dim bmp As B4XBitmap = v.Snapshot
    bmp.Resize(1100, 800, False).WriteToStream(out,100,"PNG")
    out.Close
End Sub



[aminoacid]

Thanks oparra! That did work.
However I did find out what the problem was. .... it was not in my code.
I had a text box placed in Designer that was out of the bounds of the 1100 x 800 form. I did not notice that I had placed it there. So I presume that because of this, the form size I specified was overridden with a new size to encompass the text box. Once I removed the textbox, the PNG was created in the expected size.
Running your code did resize the PNG but it also included the runaway textbox and that's how I found it.
Tx again!
