B4A Library CrossView

Discussion in 'Additional libraries, classes and official updates' started by Johan Schoeman, Jul 20, 2015.

  1. Johan Schoeman

    Johan Schoeman Expert Licensed User

    The attached project wraps this Github project. The library files are in the /files folder of the B4A project. Copy them to your additional library folder. Posting the following:
    1. B4A project
    2. Java Source code


    crossview
    Author:
    Johan Schoeman
    Version: 1
    • CrossView
      Fields:
      • ba As BA
      Methods:
      • BringToFront
      • DesignerCreateView (base As PanelWrapper, lw As LabelWrapper, props As Map)
      • Initialize (EventName As String)
      • Invalidate
      • Invalidate2 (arg0 As Rect)
      • Invalidate3 (arg0 As Int, arg1 As Int, arg2 As Int, arg3 As Int)
      • IsInitialized As Boolean
      • RemoveView
      • RequestFocus As Boolean
      • SendToBack
      • SetBackgroundImage (arg0 As Bitmap)
      • SetColorAnimated (arg0 As Int, arg1 As Int, arg2 As Int)
      • SetLayout (arg0 As Int, arg1 As Int, arg2 As Int, arg3 As Int)
      • SetLayoutAnimated (arg0 As Int, arg1 As Int, arg2 As Int, arg3 As Int, arg4 As Int)
      • SetVisibleAnimated (arg0 As Int, arg1 As Boolean)
      • setCross_1
        Transition to "X"
      • setPlus_1
        Transition to "+"
      • toggle_1
        Tell this view to switch states from cross to plus, or back, using the default animation duration.
        Return type: @return:an integer flag that represents the new state after toggling.
        This will be either {@link #FLAG_STATE_PLUS} or {@link #FLAG_STATE_CROSS}
      Properties:
      • Background As Drawable
      • Color As Int [write only]
      • CrossAnimationDuration As Long [write only]
      • CrossColor As Int [write only]
      • Cross_2 As Long [write only]
        Transition to "X" over the given animation duration
      • Enabled As Boolean
      • Height As Int
      • Left As Int
      • Plus_2 As Long [write only]
        Transition to "+" over the given animation duration
      • StrokeWidth As Float [write only]
      • Tag As Object
      • Top As Int
      • Visible As Boolean
      • Width As Int
      • toggle_2 As Long [write only]
        Tell this view to switch states from cross to plus, or back.


    Attached Files:

    Isac, shashkiranr, DonManfred and 2 others like this.
  2. ArminKH

    ArminKH Well-Known Member

    thank u 4 sharing
