Android Question File Rotation... Can't Get It Done!

Discussion in 'Android Questions' started by Shadow&Max, May 25, 2014.

  1. Shadow&Max

    Shadow&Max Active Member Licensed User

    This is weird.

    I can rotate the bitmap ok, but the actual container doesn't change.

    I want to rotate a bitmap that's in portrait mode, to landscape, and save it as that landscape size. It appears that when I rotate the bitmap, and save it, it's saved as the horizontal picture, inside a portrait container, much of which is black above and below the rotated pic. So, in what's saved, I end up with the rotated image the width of which is the width of the portrait container and the height is only a small portion of the portrait picture, but the rotated picture is in the correct proportions.

    I've tried several of the things I found on the site, but still come up with the same result. Here's where I am now:

    Code:
    Sub RotateView(v As View, bmp As Bitmap, degrees As Float)

    Dim c As Canvas

    Dim R As Rect

    'Dim imgratio As Long
        Dim hh2,hw2 As Int
        hh2 = v.Height
        hw2 = v.Width

        c.Initialize(v)
        R.Initialize(
    0,0,v.Height,v.Width)
        c.DrawRect(R,
    Colors.transparent,True,0)
        c.DrawBitmapRotated(bmp,
    Null,R,degrees)

        v.SetBackgroundImage(c.Bitmap)

        v.Invalidate


    Dim out As OutputStream

    Dim rfile As String

        rfile =
    "rotatetemp.jpg"
        out =
    File.OpenOutput(File.DirInternal, rfile, False)
        c.Bitmap.WriteToStream(out,
    100"JPEG")
        out.Close
        ResizePreviewPhoto(
    File.DirInternal,rfile)
        SetPreviewLayout

    End Sub

    Sub SetPreviewLayout  '(bwidth As Int, bheight As Int)


    'ivPreview.Height = bwidth
        'ivPreview.Width = bheight

        ivPreview.Top = (btnShoot.Top /
    2) - (ivPreview.Height / 2)
        ivPreview.Left = iv.Left + ((iv.Width /
    2) - (ivPreview.Width / 2) )

    DoEvents
        btnRotateLeft.Top = (ivPreview.Top + ivPreview.Height /
    2) - btnRotateLeft.Height / 2
        btnRotateRight.Top = btnRotateLeft.Top
        btnRotateLeft.Left = ivPreview.Left - btnRotateLeft.Width -
    20dip
        btnRotateRight.Left = ivPreview.Left + ivPreview.Width +
    20dip
    End Sub

    Sub ResizePreviewPhoto (Dir As String, FileName As String)

    Dim bm2 As Bitmap
        bm2.InitializeSample(Dir, FileName,
    100dip100dip)
        hip = bm2.Height
        wip = bm2.Width
        ivPreview.Bitmap = bm2

    If hip = wip Then 'It's Square
                ivPreview.Height = 100dip
                ivPreview.Width =
    100dip

    Else If hip > wip Then 'It's Portrait
                imageratio = (wip / hip)
                ivPreview.Height =
    100dip
                ivPreview.Width = ivPreview.Height  * imageratio
    '- 20dip
            Else 'It's Landscape
                imageratio = (hip / wip)
                ivPreview.Width =
    100dip 'pnl.Width '- 40dip
                ivPreview.Height = ivPreview.Width * imageratio

    End If
    End Sub
    I don't know what to do next. This SHOULD work, shouldn't it? If not, where'd I go wrong here?

  2. Erel

    Erel Administrator Staff Member Licensed User

    What is the size of v?

  3. strat

    strat Active Member Licensed User

    This works but causes some blur effects after rotation. I couldn't find why it occurs.




    Code:
    'Needed Libraries : Reflection



    Sub Process_Globals
    End Sub

    Sub Globals

    Dim masterpic As Bitmap

    Dim button1 As Button

    Dim button2 As Button

    Dim picture As ImageView

    Dim cnv As Canvas
    End Sub

    Sub Activity_Create(FirstTime As Boolean)
        button1.Initialize(
    "button1")

    Activity.AddView(button1,20%x,90%y,30%x,10%y)
        button1.Text=
    "Draw"

        button2.Initialize(
    "button2")

    Activity.AddView(button2,60%x,90%y,30%x,10%y)
        button2.Text=
    "Rotate"

        picture.Initialize(
    "picture")

    Activity.AddView(picture,0,0,50%x,50%y)
    End Sub

    Sub button1_click
        cnv.Initialize(picture)

    For i=1 To 100
            cnv.DrawLine(
    Rnd(0,25%x),Rnd(0,25%y),Rnd(25%x,50%x),Rnd(25%y,50%y),Colors.ARGB(255,Rnd(50,255),Rnd(50,255),Rnd(50,255)),1)

    Next

    End Sub

    Sub button2_click
        masterpic.Initialize3(picture.Bitmap)
        masterpic.
        rotatepicture(
    30)'Rotate the picture 30 degree at every step
        picture.Bitmap=masterpic
    End Sub

    Sub Activity_Resume

    End Sub

    Sub Activity_Pause (UserClosed As Boolean)

    End Sub

    Sub rotatepicture( angle As Int)

    Dim bb As Bitmap

    Dim pwo As Int

    Dim sqp As Int

    Dim pho As Int

    Dim recto As Rect

    Dim c As Canvas

      pwo = masterpic.Width
      pho = masterpic.Height

    'pwo=100
      'pho=133
      sqp = pwo 'for square imaqe


    If pwo <> pho Then

    'set longer side
          sqp = pho

    If pwo > pho Then sqp = pwo


    'first RESIZE to square
          bb = CreateScaledBitmap (masterpic, sqp, sqp, True)

    End If

      bb.InitializeMutable(sqp,sqp)
      recto.Initialize(
    00,sqp,sqp)


    'ROTATE masterPic into bb
      c.Initialize2(bb)
      c.DrawBitmapRotated(masterpic,
    Null, recto, angle) 'Draw the new image
      masterpic.Initialize3(bb)


    'RESIZE back inverse, if pic was not square
      If pwo <> pho Then
          masterpic = CreateScaledBitmap (bb, pho, pwo,
    True)

    End If

    End Sub

    Sub CreateScaledBitmap(Original As Bitmap, Width As Int, Height As Int, Filter As Boolean) As Bitmap

    Dim rf As Reflector

    Dim bm As Bitmap
      bm = rf.RunStaticMethod(
    "android.graphics.Bitmap""createScaledBitmap", _

    Array As Object(Original, Width, Height, Filter), _

    Array As String("android.graphics.Bitmap""java.lang.int""java.lang.int""java.lang.boolean"))

    Return bm
    End Sub

  4. Shadow&Max

    Shadow&Max Active Member Licensed User

    v is a imageview... ivPreview... 200h, 112 w originally...

    What I'm doing here is this:

    I have a pic on the original screen. I bring up a panel with a small preview pic, that gets rotated. When the user's happy with that, I'll take the temp file I'm creating during the rotation, and copy it over the original file on the original screen.

    I'm not sure what the original dimensions of the picture are on the main screen. But I reload the picture into that ivPreview, manipulate it there, and then will go back. The problem is that the preview image is out of whack...

    FYI, I wasn't saving the preview image at first, but I added the code because the preview pane would shrink in weird ways each time. The proportions never stayed the same, becoming thinner and thinner.

    The original picture...

    [​IMG]

    The original preview pic:

    [​IMG]

    Rotated once:

    [​IMG]

    Rotated again:

    [​IMG]

    Last edited: May 25, 2014
  5. Erel

    Erel Administrator Staff Member Licensed User

    Can you upload this image file?

  6. Shadow&Max

    Shadow&Max Active Member Licensed User

    Sure... it happens with ALL pictures though...


    Attached Files:

  7. Shadow&Max

    Shadow&Max Active Member Licensed User

    Let me make sure I'm clear about what I'm trying to do...

    The picture attached is on the main screen. When they click the edit button, the second shot comes up. In it is a preview made by calling ResizePreviewPhoto wit the dir and file name of the file that's in the main screen. ResizePreviewPhoto shrinks it down to the preview size.

    I rotate the picture, as many times as the user wants, and then, when they're satisfied, I rotate the existing image and copy it to a temp file, and if they stay with it, delete the first, original file, and rename the temp file to a new name, then store it in the database...

    When the preview opens, it's correct, as shown, on the first rotate, it shrinks, but the aspect is completely wrong.. Then, on the second rotate, it's smaller, but the aspect is correct as it's upside down portrait, but the smaller size. Then it rotates again and gets smaller once more... But at that smaller size it stays, but constantly degrades the background of the ivPreview ImageView to some pixilated mess.

  8. Erel

    Erel Administrator Staff Member Licensed User

    Based on this solution: http://stackoverflow.com/questions/...esults-in-squashed-image-need-a-true-rotate-b

    Code:
    Sub Activity_Create(FirstTime As Boolean)

    Dim NewImage As Bitmap = RotateImage(LoadBitmap(File.DirAssets, "MVC-748F.jpg"), 180)

    Dim iv As ImageView
       iv.Initialize(
    "")

    Activity.AddView(iv, 00, NewImage.Width, NewImage.Height)
       iv.SetBackgroundImage(NewImage)
       iv.Gravity =
    Gravity.FILL
    End Sub

    Sub RotateImage(original As Bitmap, degree As Float) As Bitmap

    Dim matrix As JavaObject

    matrix.InitializeNewInstance("android.graphics.Matrix"Null)

    matrix.RunMethod("postRotate"Array(degree))

    Dim bmp As JavaObject
       bmp.InitializeStatic(
    "android.graphics.Bitmap")

    Dim NewImage As Bitmap = bmp.RunMethod("createBitmap"Array(original, 00, original.Width, original.Height, _

    matrixTrue))

    Return NewImage
    End Sub

    asales, pesquera and Shadow&Max like this.
  9. Shadow&Max

    Shadow&Max Active Member Licensed User

    Thanks Erel... I'll try this out and see how it goes... Really appreciate the feedback...

  10. Shadow&Max

    Shadow&Max Active Member Licensed User

    Thanks Erel... Took a while to get it right, but you put me on the right track. I had a lot of fudging to do with the two panels and multiple ImageViews... Got it though... Thanks!

  11. squaremation

    squaremation Active Member Licensed User

    Code:
    matrix.RunMethod("postRotate"Array(degree))
    In this line I get the error, 'as' expected ?

  12. Shadow&Max

    Shadow&Max Active Member Licensed User

    Post some of your code so we can see what you're doing. I'm using that call without issue...

  13. squaremation

    squaremation Active Member Licensed User

    Code:
    Sub RotateImage(minHand As Bitmap, degree As Float) As Bitmap

    Dim matrix As JavaObject

    Dim bmp As JavaObject

    matrix.InitializeNewInstance("android.graphics.Matrix"Null)

    matrix.RunMethod("postRotate"Array(degree))
      bmp.InitializeStatic(
    "android.graphics.Bitmap")

    Dim NewImage As Bitmap = bmp.RunMethod("createBitmap"Array(minHand, 00, minHand.Width, minHand.Height, _

    matrixTrue))

    Return NewImage
    End Sub

  14. Shadow&Max

    Shadow&Max Active Member Licensed User

    Are you passing the degrees to rotate when you call this and is that number passed a variable?

  15. squaremation

    squaremation Active Member Licensed User

    Code:
    Dim NewImage As Bitmap = RotateImage(LoadBitmap(File.DirAssets, "min.png"), 6)

  16. Shadow&Max

    Shadow&Max Active Member Licensed User

    Just as a test... call it something other than newimage in the call.

    Also, I found that breaking the lines u helped me for some reason... maybe it was just visual, but I recall that I broke it up for a reason...

    May be a shot in the dark because that same code is working fine for me, but try:

    Code:
    Dim TestImage as Bitmap
    TestImage =
    LoadBitmap(File.DirAssets, "min.png")
    TestImage = RotateImage(TestImage,
    6)

    Last edited: Jun 11, 2014
  17. squaremation

    squaremation Active Member Licensed User

    Tried it no go :(

    For some reason i can't get any methods to rotate a image to work.
    I must be doing something wrong it seems straight forward, idk :confused:

  18. Shadow&Max

    Shadow&Max Active Member Licensed User

    When you tried that other code, did you get the same error or did it just not rotate?

  19. squaremation

    squaremation Active Member Licensed User

    same error

    Code:
    Sub Process_Globals

    Dim rv As RemoteViews

    Dim Timer01 As Timer

    End Sub

    Sub Service_Create
        rv =
    ConfigureHomeWidget("LayoutFile""rv"0"Analog Clock Widget")

    End Sub

    Sub Service_Start (StartingIntent As Intent)

    If rv.HandleWidgetEvents(StartingIntent) Then Return
        Timer01.Initialize(
    "Timer01"60000' 1000 = 1 second
        Timer01.Enabled = True
    End Sub
    Sub Timer01_Tick
        rv_RequestUpdate
    End Sub
    Sub rv_RequestUpdate

    'Dim minhand As Bitmap = LoadBitmap(File.DirAssets, "min.png")
        'ShowMinute(minhand)
        'MinuteTick("min.png" As Bitmap)
        'Dim TestImage As Bitmap = RotateImage(LoadBitmap(File.DirAssets, "min.png"), 6)
        Dim TestImage As Bitmap
        TestImage =
    LoadBitmap(File.DirAssets, "min.png")
        TestImage = RotateImage(TestImage,
    6)
        rv.UpdateWidget
    End Sub
    Sub rv_Disabled

    StopService("")
    End Sub

    Sub Service_Destroy

    End Sub
    'Sub ShowMinute(bmp As Bitmap)
    '
    '      Dim rbmp As RSImageProcessing
    '      mBmp=rbmp.rotateBitmap(bmp, -90)
    'End Sub
    Sub RotateImage(minHand As Bitmap, degree As Float) As Bitmap

    Dim matrix As JavaObject

    Dim bmp As JavaObject

    matrix.InitializeNewInstance("android.graphics.Matrix"Null)

    matrix.RunMethod ("postRotate"Array(degree))
      bmp.InitializeStatic(
    "android.graphics.Bitmap")

    Dim TestImage As Bitmap = bmp.RunMethod("createBitmap"Array(minHand, 00, minHand.Width, minHand.Height, _

    matrixTrue))

    Return TestImage
    End Sub

  20. aggelos

    aggelos Member Licensed User

    For the next guy who comes across the rotateimage

    if you get the error, 'as' expected
    Try changing the lines
    Code:
    matrix.RunMethod ("postRotate"Array(degree))
    to
    matrix.RunMethod ("postRotate"Array as Object(degree))

    and

    Dim TestImage AsBitmap = bmp.RunMethod("createBitmap"Array(minHand, 00, minHand.Width, minHand.Height, _matrixTrue))
    to
    Dim TestImage AsBitmap = bmp.RunMethod("createBitmap"Array as Object(minHand, 00, minHand.Width, minHand.Height, _matrixTrue))
