Android Question How can I open file from FileProvider.SharedFolder?

PhrotonX · Apr 16, 2025

I tried following some tutorials found in this forum, but I couldn't make it work. I often get InvocationTargetException errors. If not, I get "Media not found" on Android's Photos app when opening some files of MIME type images/*.

B4X:

Public Sub GetAttachmentFilePath(attachment_id As Long) As String
    Log("DirDefautlExternal: " & Starter.Permissions.GetSafeDirDefaultExternal(m_fileRepository.DIRECTORY))
    For Each item As String In File.ListFiles(Starter.Permissions.GetSafeDirDefaultExternal(m_fileRepository.DIRECTORY))
        Log("File from DirDefaultExternal: " & item)
    Next

    Return File.Combine(Starter.Permissions.GetSafeDirDefaultExternal(m_fileRepository.DIRECTORY), _
    GetAttachment(attachment_id).GetFilename)
End Sub

' Returns true if the insertion succeeded.
Public Sub OpenAttachment(attachment_id As Long) As Boolean
    Try
        Dim filePath As String = GetAttachmentFilePath(attachment_id)
        Dim fileName As String = GetAttachment(attachment_id).GetFilename

        Log("filePath: " & filePath)
        Log("fileName: " & fileName)

        File.Copy(Starter.Permissions.GetSafeDirDefaultExternal(m_fileRepository.DIRECTORY), _
        fileName, Starter.Provider.SharedFolder, fileName)

        Log("SharedFolder: " & Starter.Provider.SharedFolder)

        For Each item As String In File.ListFiles(Starter.Provider.SharedFolder)
            Log("File from SharedFolder: " & item)
        Next

        Dim intentObj As Intent
        intentObj.Initialize(intentObj.ACTION_VIEW, "")
        ' intentObj.Initialize(intentObj.ACTION_VIEW, File.Combine(Starter.Provider.SharedFolder, fileName)) ' Doesn't work
        Starter.Provider.SetFileUriAsIntentData(intentObj, fileName) ' Doesn't work
        'intentObj.SetComponent("android/com.android.internal.app.ResolverActivity")
        intentObj.SetType("image/*")
        StartActivity(intentObj)

        Return True
    Catch
        Log(LastException)
    End Try

    Return False
End Sub

The logs:

B4X:

DirDefautlExternal: /storage/emulated/0/Android/data/com.cm.todolist/files/attachments
File from DirDefaultExternal: 1744788485734_IMG_20250407_204747.jpg
filePath: /storage/emulated/0/Android/data/com.cm.todolist/files/attachments/1744788485734_IMG_20250407_204747.jpg
fileName: 1744788485734_IMG_20250407_204747.jpg
SharedFolder: /data/user/0/com.cm.todolist/files/shared
File from SharedFolder: 1744788485734_IMG_20250407_204747.jpg
Error occurred on line: 33 (FileProvider)
java.lang.reflect.InvocationTargetException
    at java.lang.reflect.Method.invoke(Native Method)
    at anywheresoftware.b4j.object.JavaObject.RunMethod(JavaObject.java:132)
    at com.cm.todolist.fileprovider._getfileuri(fileprovider.java:147)
    at com.cm.todolist.fileprovider._setfileuriasintentdata(fileprovider.java:98)
    at java.lang.reflect.Method.invoke(Native Method)
    at anywheresoftware.b4a.shell.Shell.runMethod(Shell.java:732)
    at anywheresoftware.b4a.shell.Shell.raiseEventImpl(Shell.java:351)
    at anywheresoftware.b4a.shell.Shell.raiseEvent(Shell.java:255)
    at java.lang.reflect.Method.invoke(Native Method)
    at anywheresoftware.b4a.ShellBA.raiseEvent2(ShellBA.java:157)
    at anywheresoftware.b4a.debug.Debug.delegate(Debug.java:262)
    at com.cm.todolist.attachmentviewmodel._openattachment(attachmentviewmodel.java:203)
    at com.cm.todolist.editoractivity._clvattachments_itemclick(editoractivity.java:1425)
    at java.lang.reflect.Method.invoke(Native Method)
    at anywheresoftware.b4a.shell.Shell.runMethod(Shell.java:732)
    at anywheresoftware.b4a.shell.Shell.raiseEventImpl(Shell.java:351)
    at anywheresoftware.b4a.shell.Shell.raiseEvent(Shell.java:255)
    at java.lang.reflect.Method.invoke(Native Method)
    at anywheresoftware.b4a.ShellBA.raiseEvent2(ShellBA.java:157)
    at anywheresoftware.b4a.keywords.Common.CallSub4(Common.java:1114)
    at anywheresoftware.b4a.keywords.Common.CallSubNew3(Common.java:1077)
    at b4a.example3.customlistview$ResumableSub_PanelClickHandler.resume(customlistview.java:805)
    at b4a.example3.customlistview._panelclickhandler(customlistview.java:748)
    at b4a.example3.customlistview._panel_click(customlistview.java:735)
    at java.lang.reflect.Method.invoke(Native Method)
    at anywheresoftware.b4a.BA.raiseEvent2(BA.java:221)
    at anywheresoftware.b4a.BA.raiseEvent(BA.java:201)
    at anywheresoftware.b4a.objects.ViewWrapper$1.onClick(ViewWrapper.java:80)
    at android.view.View.performClick(View.java:8028)
    at android.view.View.performClickInternal(View.java:8005)
    at android.view.View.-$$Nest$mperformClickInternal(Unknown Source:0)
    at android.view.View$PerformClick.run(View.java:31229)
    at android.os.Handler.handleCallback(Handler.java:959)
    at android.os.Handler.dispatchMessage(Handler.java:100)
    at android.os.Looper.loopOnce(Looper.java:232)
    at android.os.Looper.loop(Looper.java:317)
    at android.app.ActivityThread.main(ActivityThread.java:8705)
    at java.lang.reflect.Method.invoke(Native Method)
    at com.android.internal.os.RuntimeInit$MethodAndArgsCaller.run(RuntimeInit.java:580)
    at com.android.internal.os.ZygoteInit.main(ZygoteInit.java:886)
Caused by: java.lang.IllegalArgumentException: Failed to find configured root that contains /data/data/com.cm.todolist/files/shared/1744788485734_IMG_20250407_204747.jpg
    at androidx.core.content.FileProvider$SimplePathStrategy.getUriForFile(FileProvider.java:825)
    at androidx.core.content.FileProvider.getUriForFile(FileProvider.java:450)
    ... 40 more
(Exception) java.lang.Exception:  java.lang.reflect.InvocationTargetException

b4x-de · Apr 16, 2025

Did you configure your paths for the file provider in your Manifest?

PhrotonX · Apr 16, 2025

b4x-de said:
Did you configure your paths for the file provider in your Manifest?

Here is my manifest:

B4X:

'This code will be applied to the manifest file during compilation.
'You do not need to modify it in most cases.
'See this link for for more information: http://www.b4x.com/forum/showthread.php?p=78136
AddManifestText(
<uses-sdk android:minSdkVersion="24"
android:targetSdkVersion="33" />
<supports-screens android:largeScreens="true"
    android:debuggable="true"
    android:normalScreens="true"
    android:smallScreens="true"
    android:anyDensity="true"/>)
SetApplicationAttribute(android:icon, "@drawable/icon")
SetApplicationAttribute(android:label, "$LABEL$")
AddManifestText(
<uses-permission
  android:name="android.permission.WRITE_EXTERNAL_STORAGE"
  android:maxSdkVersion="33" />
)
AddManifestText(
<uses-permission
  android:name="android.permission.READ_EXTERNAL_STORAGE"
  android:maxSdkVersion="33" />
)
AddManifestText(
<uses-permission
  android:name="android.permission.MANAGE_EXTERNAL_STORAGE"
  android:maxSdkVersion="33" />
)

AddApplicationText(
  <provider
  android:name="android.support.v4.content.FileProvider"
  android:authorities="$PACKAGE$.provider"
  android:exported="false"
  android:grantUriPermissions="true">
  <meta-data
  android:name="android.support.FILE_PROVIDER_PATHS"
  android:resource="@xml/provider_paths"/>
  </provider>
)
CreateResource(xml, provider_paths,
    <paths xmlns:android="http://schemas.android.com/apk/res/android">
    <external-path name="root" path="" />
</paths>
)
'End of default text.

b4x-de · Apr 17, 2025

Please double check your external-path for sharing. Have a look here:

save and open external files in 26+

To be compatible with android:targetSdkVersion="26" I tried to create and then download, save and then open/view files of various types. I can do so using rp As RuntimePermissions (thanks to Erels tutorial), but not yet in an external directory (to survive app uninstalls). Is there another...

www.b4x.com

Erel · Apr 17, 2025

You are over-complicating things. Start with this example: https://www.b4x.com/android/forum/threads/class-fileprovider-share-files.97865

Tip: no reason to use rp.GetSafeDirDefaultExternal.

See this flow chart: https://www.b4x.com/android/forum/threads/flow-chart-to-help-choose-folder.132787/#content

PhrotonX · Apr 17, 2025

Erel said:
You are over-complicating things. Start with this example: https://www.b4x.com/android/forum/threads/class-fileprovider-share-files.97865

I have actually followed that exact same example before posting this thread. I tried copying my files from source folder into FIleProvider.SharedFolder and then tried opening the filename of the file copied into that folder. However, it doesn't work.

Erel · Apr 17, 2025

The example works as-is. Start from there and see why it fails with your code. And as I wrote, there is no reason to use GetSafeDirDefaultExternal.

b4x-de · Apr 19, 2025

PhrotonX said:
I have actually followed that exact same example before posting this thread. I tried copying my files from source folder into FIleProvider.SharedFolder and then tried opening the filename of the file copied into that folder. However, it doesn't work.

When you have followed this example, you should have noticed this line in its Manifest:

CreateResource(xml, provider_paths,
<files-path name="name" path="shared" />
)

In your Manifest the line is:

CreateResource(xml, provider_paths,
<paths xmlns:android="http://schemas.android.com/apk/res/android">
<external-path name="root" path="" />
</paths>
)

It makes a difference, whether you have an empty path (your Manifest) or have a folder path "shared" (example). You can't access in your code to the path "shared" because it is missing in your Manifest.

PhrotonX · Apr 20, 2025

I have already fixed this issue by doing some trial and error.

Erel · Apr 20, 2025

You should post the solution.
