Android Code Snippet [B4X] [XUI] Rectangle image with rounded corners

Discussion in 'Code Snippets' started by Erel, Nov 19, 2017.

  1. Erel

    Erel Administrator Staff Member Licensed User

    Code to create a rectangle image with rounded corners:

    [​IMG]

    Compatible with B4A, B4i and B4J. Depends on XUI library v1.47+.

    Code:
    Sub CreateRoundRectBitmap (Input As B4XBitmap, Radius As Float) As B4XBitmap

    Dim BorderColor As Int = xui.Color_Black

    Dim BorderWidth As Int = 4dip

    Dim c As B4XCanvas

    Dim xview As B4XView = xui.CreatePanel("")
       xview.SetLayoutAnimated(
    000, Input.Width, Input.Height)
       c.Initialize(xview)

    Dim path As B4XPath

    path.InitializeRoundedRect(c.TargetRect, Radius)
       c.ClipPath(
    path)
       c.DrawRect(c.TargetRect, BorderColor,
    True, BorderWidth) 'border
       c.RemoveClip

    Dim r As B4XRect
       r.Initialize(BorderWidth, BorderWidth, c.TargetRect.Width - BorderWidth, c.TargetRect.Height - BorderWidth)

    path.InitializeRoundedRect(r, Radius - 0.7 * BorderWidth)
       c.ClipPath(
    path)
       c.DrawBitmap(Input, r)
       c.RemoveClip
       c.Invalidate

    Dim res As B4XBitmap = c.CreateBitmap
       c.Release

    Return res
    End Sub
    Usage example:
    Code:
    Dim img As B4XBitmap = xui.LoadBitmapResize(File.DirAssets, "image.png", ImageView1.Width, ImageView1.Height, True)
    ImageView1.SetBitmap(CreateRoundRectBitmap(img,
    20dip)) 'ImageView1 type is set to B4XView

  2. Serinter

    Serinter Member Licensed User

    B4J CODE ERROR

    Code:
    Sub Process_Globals

    Private fx As JFX

    Private MainForm As Form

    Private ImageView1 As B4XView

    Dim xui As XUI
    End Sub

    Sub AppStart (Form1 As Form, Args() As String)
        MainForm = Form1


    Dim img As B4XBitmap = xui.LoadBitmapResize(File.DirAssets, "image.png", ImageView1.Width, ImageView1.Height, True)
        ImageView1.SetBitmap(CreateRoundRectBitmap(img,
    20dip)) 'ImageView1 type is set to B4XView

        MainForm.RootPane.AddNode(ImageView1,
    450,350,100,100)

        MainForm.Show
    End Sub


    Sub CreateRoundRectBitmap (Input As B4XBitmap, Radius As Float) As B4XBitmap

    Dim BorderColor As Int = xui.Color_Black

    Dim BorderWidth As Int = 4dip

    Dim c As B4XCanvas

    Dim xview As B4XView = xui.CreatePanel("")
        xview.SetLayoutAnimated(
    000, Input.Width, Input.Height)
        c.Initialize(xview)

    Dim path As B4XPath

    path.InitializeRoundedRect(c.TargetRect, Radius)
        c.ClipPath(
    path)
        c.DrawRect(c.TargetRect, BorderColor,
    True, BorderWidth) 'border
        c.RemoveClip

    Dim r As B4XRect
        r.Initialize(BorderWidth, BorderWidth, c.TargetRect.Width - BorderWidth, c.TargetRect.Height - BorderWidth)

    path.InitializeRoundedRect(r, Radius - 0.7 * BorderWidth)
        c.ClipPath(
    path)
        c.DrawBitmap(Input, r)
        c.RemoveClip
        c.Invalidate

    Dim res As B4XBitmap = c.CreateBitmap
        c.Release

    Return res

    End Sub

    'Return true to allow the default exceptions handler to handle the uncaught exception.
    Sub Application_Error (Error As Exception, StackTrace As StringAs Boolean

    Return True
    End Sub
    ERROR!

    B4J Versión: 5.90
    Parseando código. (0.00s)
    Compilando código (0.15s)
    Compilado código de diseños (0.00s)
    Organizando librerías. (0.00s)
    Compilando el código Java generado. Error
    B4J line: 17
    ImageView1.SetBitmap(CreateRoundRectBitmap(img, 2
    javac 1.8.0_144
    src\b4j\example\main.java:93: error: package android.graphics does not exist
    _imageview1.SetBitmap((android.graphics.Bitmap)(_createroundrectbitmap(_img,(float) (anywheresoftware.b4a.keywords.Common.DipToCurrent((int) (20)))).getObject()));
    ^
    1 error

    Removing the "dip" text remains the same error.
    I've missed something??

    Last edited: Nov 19, 2017
  3. Erel

    Erel Administrator Staff Member Licensed User

    Looks like you have added the B4A version of XUI to B4J.

    There are three libraries:
    XUI - B4A
    jXUI - B4J
    iXUI - B4i

  4. Serinter

    Serinter Member Licensed User

    Upppps. My fault. I'm going to correct this. Thanks again and forgive my impatience!!!

    Last edited: Nov 19, 2017
  5. Serinter

    Serinter Member Licensed User

    Ok. I must be a perfect idiot... but I can't see how to put this to work!!!!
    Now a new error:

    Code:
    Sub Process_Globals

    Private fx As JFX

    Private MainForm As Form

    Private ImageView1 As B4XView

    Dim xui As XUI
    End Sub

    Sub AppStart (Form1 As Form, Args() As String)
        MainForm = Form1


    Dim img As B4XBitmap = xui.LoadBitmapResize(File.DirAssets, "image.png", ImageView1.Width, ImageView1.Height, True)
        ImageView1.SetBitmap(CreateRoundRectBitmap(img,
    20dip)) 'ImageView1 type is set to B4XView

        MainForm.RootPane.AddNode(ImageView1,
    450,350,100,100)

        MainForm.Show
    End Sub


    Sub CreateRoundRectBitmap (Input As B4XBitmap, Radius As Float) As B4XBitmap

    Dim BorderColor As Int = xui.Color_Black

    Dim BorderWidth As Int = 4dip

    Dim c As B4XCanvas

    Dim xview As B4XView = xui.CreatePanel("")
        xview.SetLayoutAnimated(
    000, Input.Width, Input.Height)
        c.Initialize(xview)

    Dim path As B4XPath

    path.InitializeRoundedRect(c.TargetRect, Radius)
        c.ClipPath(
    path)
        c.DrawRect(c.TargetRect, BorderColor,
    True, BorderWidth) 'border
        c.RemoveClip

    Dim r As B4XRect
        r.Initialize(BorderWidth, BorderWidth, c.TargetRect.Width - BorderWidth, c.TargetRect.Height - BorderWidth)

    path.InitializeRoundedRect(r, Radius - 0.7 * BorderWidth)
        c.ClipPath(
    path)
        c.DrawBitmap(Input, r)
        c.RemoveClip
        c.Invalidate

    Dim res As B4XBitmap = c.CreateBitmap
        c.Release

    Return res

    End Sub

    'Return true to allow the default exceptions handler to handle the uncaught exception.
    Sub Application_Error (Error As Exception, StackTrace As StringAs Boolean

    Return True
    End Sub
    Ha ocurrido un error en la línea: 16 (Main)
    java.lang.RuntimeException: Object should first be initialized (B4XView).

    Any help, please!
    I'm obfuscated and I don't see where's my fault code. I'm getting crazy with this

  6. Erel

    Erel Administrator Staff Member Licensed User

    CreateRoundRectBitmap creates a bitmap. It doesn't return any view. You need to create the ImageView.

    I recommend you to add views with the designer. Create a new layout. Add an ImageView and then call MainForm.RootPane.LoadLayout(...).
    Remove the line that adds ImageView1 to RootPane.

    If you want to do it programmatically:
    Code:
    Dim iv As ImageView
    iv.Initialize(
    "")
    Dim b4xview As B4XView = iv
    MainForm.RootPane.AddNode(b4xview, ...)
    Dim img As B4XBitmap = ...
    b4xview.SetBitmap(CreateRoundRectBitmap(...))

    Last edited: Nov 20, 2017
    Procesor and Serinter like this.
  7. Serinter

    Serinter Member Licensed User

    Of course!!! What a silly and blind I was not seeing this!
    Thank you very much for the inconvenience Erel. You are a genious!!
