iOS Question B4XPageIndicator have low quality

webhost.company

Active Member
Licensed User
Longtime User
The B4XPageIndicator1 is a good library for B4X
Only, that has an important the problem
The circles are of poor quality
That is not sharp and seem lost quality


webhost.company

Active Member
Licensed User
Longtime User
Please see circles, the circles round is not sharp


Attachments

  • test.zip
    4 KB · Views: 111
  • photo_2021-10-17_12-34-42.jpg
    68.9 KB · Views: 164
Upvote 0

Erel

B4X founder
Staff member
Licensed User
Longtime User
Change Base_Resize code to:
B4X:
Private Sub Base_Resize (Width As Double, Height As Double)
    #if B4i
    Dim scale As Float = GetDeviceLayoutValues.NonnormalizedScale
    #else
    Dim scale As Float = 1
    #end if
    If bc.IsInitialized = False Or bc.mWidth <> Width * scale Then
        bc.Initialize(Width * scale, 20dip * scale)
        r = 5dip * scale
        gap = 15dip * scale
        Transparent = bc.CreateBrushFromColor(xui.Color_Transparent)
        ActiveBrush = bc.CreateBrushFromColor(clr)
        InactiveBrush = bc.CreateBrushFromColor(Bit.Or(0x55000000, Bit.And(0x00FFFFFF, clr)))
    End If
    iv.SetLayoutAnimated(0, 0, 0, Width, bc.mHeight)
    Draw
End Sub

Upvote 0

webhost.company

Active Member
Licensed User
Longtime User
Change Base_Resize code to:
B4X:
Private Sub Base_Resize (Width As Double, Height As Double)
    #if B4i
    Dim scale As Float = GetDeviceLayoutValues.NonnormalizedScale
    #else
    Dim scale As Float = 1
    #end if
    If bc.IsInitialized = False Or bc.mWidth <> Width * scale Then
        bc.Initialize(Width * scale, 20dip * scale)
        r = 5dip * scale
        gap = 15dip * scale
        Transparent = bc.CreateBrushFromColor(xui.Color_Transparent)
        ActiveBrush = bc.CreateBrushFromColor(clr)
        InactiveBrush = bc.CreateBrushFromColor(Bit.Or(0x55000000, Bit.And(0x00FFFFFF, clr)))
    End If
    iv.SetLayoutAnimated(0, 0, 0, Width, bc.mHeight)
    Draw
End Sub
Oh that is good Thanks
Can you add this code to the B4xPageindicator library?

Upvote 0
