iOS Question iBarCode is not showing preview

[pliroforikos]

Hi
I'm trying to use iBarcode library. The example in library ref is working ok but i cant see a preview in my example project with b4xpages. On the other hand the library scans a qr code if i put one in front of camera.

Any idea?
Thank you

#Region  Project Attributes
    #ApplicationLabel: B4i BarCode
    #Version: 1.0.0
    'Orientation possible values: Portrait, LandscapeLeft, LandscapeRight and PortraitUpsideDown
    #iPhoneOrientations: Portrait, LandscapeLeft, LandscapeRight
    #iPadOrientations: Portrait, LandscapeLeft, LandscapeRight, PortraitUpsideDown
    #Target: iPhone, iPad
    #ATSEnabled: True
    #MinVersion: 8

    #PlistExtra:<key>NSCameraUsageDescription</key><string>Read barcodes</string>
#End Region

#Region Shared Files
#CustomBuildAction: folders ready, %WINDIR%\System32\Robocopy.exe,"..\..\Shared Files" "..\Files"
'Ctrl + click to sync files: ide://run?file=%WINDIR%\System32\Robocopy.exe&args=..\..\Shared+Files&args=..\Files&FilesSync=True
#End Region

'Ctrl + click to export as zip: ide://run?File=%B4X%\Zipper.jar&Args=Project.zip

Sub Class_Globals
    Private Root As B4XView
    Private xui As XUI
    Public pgQR As B4XPageBarCode

End Sub

Public Sub Initialize
'    B4XPages.GetManager.LogEvents = True
End Sub

'This event will be called once, before the page becomes visible.
Private Sub B4XPage_Created (Root1 As B4XView)
    Root = Root1
    Root.LoadLayout("MainPage")

    If Not(pgQR.IsInitialized) Then
        pgQR.Initialize
        B4XPages.AddPage("pgQR", pgQR)
    End If


End Sub

'You can see the list of page related events in the B4XPagesManager object. The event name is B4XPage.

Private Sub Button1_Click
    B4XPages.ShowPage("pgQR")
End Sub

Sub Class_Globals
    Private Root As B4XView 'ignore
    Private xui As XUI 'ignore

    Private scanner As BarcodeScanner
    Private btnStart, btnStop, btnSave As Button
    Private lblResult As Label
    Private pnlPreview As B4XView
    Private hd As HUD
End Sub

'You can add more parameters here.
Public Sub Initialize As Object
    Return Me
End Sub

'This event will be called once, before the page becomes visible.
Private Sub B4XPage_Created (Root1 As B4XView)
    Root = Root1
    Root.LoadLayout("frmBarCode")


End Sub

Private Sub B4XPage_Appear
    scanner.Initialize("scanner", pnlPreview)
    btnSave.Enabled = False
    lblResult.Text = ""
    scanner.Start
    Sleep(100)
    Dim scanrect As Rect
    scanrect.Initialize(50, 10, 250, 210)
    scanner.ScanRect = scanrect
End Sub



Sub pnlPreview_Resize (Width As Float, Height As Float)
    scanner.Resize
End Sub


Sub scanner_Ready (Success As Boolean)
    btnStart.Enabled = Success
'    btnStop.Enabled = False
    If Success = True Then
        hd.ToastMessageShow("Ready to start", False)
    Else
        hd.ToastMessageShow("Error starting scanner", True)
    End If
End Sub


Sub scanner_Detected (Codes As List)
    Dim sb As StringBuilder
    sb.Initialize
    sb.Append("Detected code:").Append(CRLF)
    For Each code As BarcodeCode In Codes
        sb.Append(code.Value).Append(CRLF)
    Next
    lblResult.Text = sb.ToString
    btnSave.Enabled = True
End Sub


Private Sub btnStart_Click
    scanner.Start
    Sleep(100)
    Dim scanrect As Rect
    scanrect.Initialize(50, 10, 250, 210)
    scanner.ScanRect = scanrect
    hd.ToastMessageShow("Start...", False)
End Sub


Private Sub btnStop_Click
    scanner.Stop
    hd.ToastMessageShow("Stopping...", False)
End Sub


Private Sub btnSave_Click
    hd.ToastMessageShow("Saving...", True)
End Sub



[Erel]

1,

 If Not(pgQR.IsInitialized) Then

This is not needed in B4XPages as B4XPage_Created will run exactly once.

2.

3. Don't initialize the scanner in B4XPage_Appear. Move it to Created. You don't want to initialize it multiple times.
