Android Tutorial [B4X] B4XTable - Load data from SQL database

Discussion in 'Tutorials & Examples' started by Erel, Feb 10, 2019.

  1. Erel

    Erel Administrator Staff Member Licensed User

    B4XTable.SetData expects a List where each entry in the list is an array of objects with the data of a single row.

    The data can come from any source you like.

    [​IMG]

    Example of loading the data from a SQL database:
    Code:
    B4XTable1.AddColumn("Customer Id", B4XTable1.COLUMN_TYPE_NUMBERS)
       B4XTable1.AddColumn(
    "Name", B4XTable1.COLUMN_TYPE_TEXT)
       B4XTable1.AddColumn(
    "Company", B4XTable1.COLUMN_TYPE_TEXT)
       B4XTable1.AddColumn(
    "Address", B4XTable1.COLUMN_TYPE_TEXT)


    Dim Data As List
       Data.Initialize

    Dim rs As ResultSet = sql.ExecQuery("SELECT CustomerId, FirstName, LastName, Company, Address FROM customers")

    Do While rs.NextRow

    Dim row(4As Object
           row(
    0) = rs.GetDouble("CustomerId")
           row(
    1) = rs.GetString("FirstName") & " " & rs.GetString("LastName")
           row(
    2) = rs.GetString("Company")

    'Some of the values are Null. We need to convert them to empty strings:
           If row(2) = Null Then row(2) = ""
           row(
    3) = rs.GetString("Address")
           Data.Add(row)

    Loop
       rs.Close
       B4XTable1.SetData(Data)
    Step #1: add the columns.
    Step #2: fill the Data list with the data coming from the SQL db.
    Step #3: call B4XTable.SetData.

    B4A project is attached.

    Database source: http://www.sqlitetutorial.net/sqlite-sample-database/


    Attached Files:

    koaunglay, ilan, DroidLyon and 17 others like this.
  2. Omar Moreno

    Omar Moreno Member Licensed User

    Greetings.

    The library is very good.
    You could show the code to load a column with SQLITE BLOB type values.

    Thank you.
