Android Question CLV, row selection error

[Mostez]

I use this two subs to load items into CLV, every thing is OK, but when I click the row, sometimes toggles row selection, and sometimes it changes selection mode to multiple rows as shown in attached picture. I tried this example but also behaves the same. did I miss something?

Sub ListNewItems()

    lstvNewWhat.Clear

    Dim rd As CLVrowData
    rd.Initialize
    Dim Ln As Int = 90dip

    rd.Description = "Create new or edit existing trip order."
    rd.RowTitle =  SysDeclare.NEW_INDEX_TRIP_ORDER
    rd.Icon = LoadBitmapResize(File.DirAssets,"order-icon.png",24dip,24dip,True)
    lstvNewWhat.add(CreateListItem(rd,False, lstvBrowseWhat.AsView.Width, Ln), SysDeclare.NEW_INDEX_TRIP_ORDER)

    rd.Description = "Add or update system list items."
    rd.RowTitle =  SysDeclare.NEW_INDEX_LIST
    rd.Icon = LoadBitmapResize(File.DirAssets,"list-icon.png",24dip,24dip,True)
    lstvNewWhat.add(CreateListItem(rd,False, lstvBrowseWhat.AsView.Width, Ln), SysDeclare.NEW_INDEX_LIST)

    rd.Description = "Create new or update existing shared contact."
    rd.RowTitle =  SysDeclare.NEW_INDEX_CONTACTS
    rd.Icon = LoadBitmapResize(File.DirAssets,"contacts-icon.png",24dip,24dip,True)
    lstvNewWhat.add(CreateListItem(rd,False, lstvBrowseWhat.AsView.Width, Ln), SysDeclare.NEW_INDEX_CONTACTS)

    rd.Description = "Update vehicles In\Out log."
    rd.RowTitle =  SysDeclare.NEW_INDEX_VEHICLES_LOGGER
    rd.Icon = LoadBitmapResize(File.DirAssets,"log-icon.png",24dip,24dip,True)
    lstvNewWhat.add(CreateListItem(rd,False, lstvBrowseWhat.AsView.Width, Ln), SysDeclare.NEW_INDEX_VEHICLES_LOGGER)

End Sub


Sub CreateListItem(RowData As CLVrowData,HideButton As Boolean, Width As Int, Height As Int) As Panel
    Dim p As Panel
    p.Initialize("")
    Activity.AddView(p, 0, 0, Width, Height)
    p.LoadLayout("CLVrow")
    p.RemoveView

    'imgRowIcon.Bitmap = RowData.Icon
    If Not (HideButton) Then imgRowIcon.Bitmap = RowData.Icon
    btnSelectRow.Visible = Not(HideButton)
    imgRowIcon.Visible = Not(HideButton)

    lblRowTitle.Text = RowData.RowTitle
    lblDescription.Text = RowData.Description
    Return p
End Sub

CLV selections code:

Private CSelectionsNew As CLVSelections
    Private CSelectionsBrowse As CLVSelections
    Private XUI As XUI

Sub Activity_Create(FirstTime As Boolean)

    Activity.LoadLayout("home")

    tabHome.LoadLayout("newwhat", Chr(0xF115)  &  " New" )
    tabHome.LoadLayout("browsewhat", Chr(0xF1E5)  &  " View" )

    lstvBrowseWhat.DefaultTextBackgroundColor = XUI.Color_White
    lstvNewWhat.DefaultTextBackgroundColor = XUI.Color_White

    CSelectionsBrowse.Initialize(lstvBrowseWhat)
    CSelectionsNew.Initialize(lstvNewWhat)

    CSelectionsBrowse.Mode = CSelectionsBrowse.MODE_SINGLE_ITEM_TEMP
    CSelectionsNew.Mode = CSelectionsNew.MODE_SINGLE_ITEM_TEMP

    ListIBrowsetems
    ListNewItems

Sub lstvNewWhat_ItemClick (Position As Int, Value As Object)

    Dim strVal As String = Value
    Dim CallActivity As Object

    CSelectionsNew.ItemClicked(Position)
    CSelectionsNew.Clear
.
.
....



[Erel]

I've never seen a case with the example where selection works incorrectly. Run the example as-is and try it.



[Mostez]

the example works OK on B4J



[Erel]

Why are you calling Clear after ItemClicked? This is wrong.



[Mostez]

Why are you calling Clear after ItemClicked? This is wrong.

just wanted to make sure that the selection is cleared, I removed this line



[Mostez]

here what is happening, when I use StartActivity after CLV item click, the problem occurred, if I commented this

StartActivity(CallActivity)

the CLV selection mode works OK, If I want to call activity, I had to wait until the selection color is faded out then call start activity, I don't know if it is the best solution, but it worked!

Sub lstvNewWhat_ItemClick (Position As Int, Value As Object)

    Dim strVal As String = Value
    Dim CallActivity As Object
    CSelectionsNew.ItemClicked(Position)

    Select strVal
        Case SysDeclare.NEW_INDEX_TRIP_ORDER
            CallActivity = TripOrders

        Case SysDeclare.NEW_INDEX_LIST
            CallActivity = Lists

        Case SysDeclare.NEW_INDEX_VEHICLES_LOGGER
            CallActivity = VehiclesLogger

        Case SysDeclare.NEW_INDEX_CONTACTS
            CallActivity = Contacts

    End Select

    Sleep(300) 'wait until selection color is faded out
    StartActivity(CallActivity)



[Erel]

Best solution is to switch to B4XPages. Everything becomes simpler and issues like this will not happen.

The Sleep solution is good.
