Android Tutorial XML Parsing with the XmlSax library

[Erel]

I agree that it is not easy to start with SAX parsing. However after writing a parser or two it is pretty easy. Note that there is no magic and it will be very similar to a parser written in Java.

Sub Process_Globals
    Dim parser As SaxParser
    Type Car(name As String, weight As String, hp As String)
    Dim myCars As List
End Sub

Sub Globals
End Sub

Sub Activity_Create(FirstTime As Boolean)
    If FirstTime Then
        parser.Initialize
        Dim in As InputStream
        in = File.OpenInput(File.DirAssets, "test.txt")
        myCars.Initialize
        parser.Parse(in, "cars")
        in.Close
    End If
    Dim c As Car
    c = myCars.Get(2)
    Log(c.name & " " & c.weight & " " & c.hp)
End Sub
Sub cars_StartElement (Uri As String, Name As String, Attributes As Attributes)
    If Name = "car" Then
        Dim c As Car
        c.Initialize
        myCars.Add(c)
    End If
End Sub
Sub cars_EndElement (Uri As String, Name As String, Text As StringBuilder)
    Dim c As Car
    c = myCars.Get(myCars.Size - 1) 'Get a reference to the last car
    Select Name
        Case "name"
            c.name = Text
        Case "weight"
            c.weight = Text
        Case "hp"
            c.hp = "Text"
    End Select
End Sub



[JogiDroid]

Well, you made it look easy, not so confusing like I had it in my mind, thanks, that was helpful putting me to right track!



[mistermentality]

I have what may be a dumb question but here goes.

In the example at the start of this thread the code of the xml parsed includes:

<item>
            <title>Phone library was updated - V1.10</title>
            <link>http://www.basic4ppc.com/forum/additional-libraries-official-updates/6859-phone-library-updated-v1-10-a.html</link>
            <pubDate>Sun, 12 Dec 2010 09:27:38 GMT</pubDate>
            <guid isPermaLink="true">http://www.basic4ppc.com/forum/additional-libraries-official-updates/6859-phone-library-updated-v1-10-a.html</guid>
        </item>

I have been trying to process code which typically includes code like this:

 </lst>
- <result name="response" numFound="37" start="0">
- <doc>
  <str name="description">A collection of theatrical trailers for the Basil Rathbone-Nigel Bruce "Sherlock Holmes" films.</str>
  <str name="identifier">SherlockHolmesTrailers</str>
  <str name="mediatype">movies</str>
  <str name="title">Sherlock Holmes Trailers</str>
  </doc>
- <doc>
  <str name="description">Based on the Sir Authur Conan Doyle story "The Dancing Men", Sherlock Holmes and Dr. Watson are placed in WWII europe to help protect a scientist and his invention from the Nazis. Basil Rathbone .... Sherlock Holmes Nigel Bruce .... Dr. John H. Watson Lionel Atwill .... Professor Moriarty Kaaren Verne .... Charlotte Eberli William Post Jr. .... Dr. Franz Tobel Dennis Hoey .... Inspector Lestrade Holmes Herbert .... Sir Reginald Bailey Mary Gordon .... Mrs. Hudson</str>
  <str name="identifier">secret_weapon</str>
  <str name="mediatype">movies</str>
  <str name="title">Sherlock Holmes and the Secret Weapon</str>
  </doc>

The problem I am having is that I cannot use the code example given because as Name it reads "str" instead of "str name", I found this by adding a message box to show the current value of Name.

I can successfully parse the xml,and get Names as "doc" for example just cannot get the values for the title or mediatype for example as it always returns just "str".

Is this because unlike the example that used "item" the xml here has spaces "str name", if so would this mean a simple solution would be to replace all occurences of "str name=" so that just the name (eg "title") was left?

I don't know much about the details of xml coding but I have seen example xml files with "string name" rather than "str name", but would this be the issue?

It is not my xml, but returned from the internet archive site at archive.org but seems to be valid xml so am wondering why it is causing me this issue.

Thanks.

Dave



[Erel]

The node name is str. The name="title" is an attribute. There can be many attributes (like in the result node).



[jscoulter]

I have been playing around with the SAX parser, but it doesnt seem to like XML as complex as the below. I have tried a number of differet things and not really got anywhere, and wondered if anyone had any ideas on how to consume this XML? I am 1/2 thinking of writing a webservice that gets the data on demand and then feeds the data back to my app. as a JSON object to simplify the data structure. I also thought of having the webservice just display a webpage, but I would rather be able to just parse the XML directly etc. via Basic4Android. Here is the XML. I pasted it in from IE to show the "-" to indicate the sub nodes etc. p.s. this is just ONE record

- <event publicID="smi:geonet.org.nz/event/3499339g">
<type>earthquake</type>
<preferredOriginID>smi:geonet.org.nz/ori/490832/GROPE</preferredOriginID>
<preferredMagnitudeID>smi:geonet.org.nz/mag/490832/GROPE/ML</preferredMagnitudeID>
- <origin publicID="smi:geonet.org.nz/ori/490832/GROPE">
<type>hypocenter</type>
<evaluationMode>manual</evaluationMode>
<evaluationStatus>confirmed</evaluationStatus>
<referenceSystemID>smigc.def.crs/EPSG/4272</referenceSystemID>
- <time>
<value>2011-04-19T01:27:20.030Z</value>
<uncertainty>0.68037</uncertainty>
</time>
- <latitude>
<value>-37.59959</value>
<uncertainty>0.06618</uncertainty>
</latitude>
- <longitude>
<value>176.18645</value>
<uncertainty>0.11012</uncertainty>
</longitude>
- <depth>
<value>188.1572</value>
<uncertainty>7.9337</uncertainty>
</depth>
<depthType>from location</depthType>
- <quality>
<azimuthalGap>250</azimuthalGap>
<minimumDistance>109.53</minimumDistance>
<maximumDistance>251.13</maximumDistance>
<usedPhaseCount>14</usedPhaseCount>
<usedStationCount>10</usedStationCount>
<standardError>0.30418</standardError>
</quality>
</origin>
- <magnitude publicID="smi:geonet.org.nz/mag/490832/GROPE/ML">
- <mag>
<value>3.421</value>
<uncertainty>0.341</uncertainty>
</mag>
<type>ML</type>
<stationCount>6</stationCount>
<originID>smi:geonet.org.nz/ori/490832/GROPE</originID>
</magnitude>
</event>



[Erel]

Doesn't seem too complex... Can you upload the XML file?



[jscoulter]

sure.see attached. Its an XML file in a zip because its 47kb and the uploader for this site only allows 19 or something.

Jeremy



[Erel]

Here is an example which parses several fields of your XML. It shouldn't be difficult to parse the other fields. It works by checking the parents list to find the current branch.

'Activity module
Sub Process_Globals
    Type Event (eventId As String _
                ,eventType As String _
                ,originId As String _
                ,magnitudeId As String _
                ,descriptionText As String _
                ,descriptionType As String _
                ,originType As String _
                ,originTimeValue As String _
                ,originTimeUncertainty As Float _
                ,originLatitudeValue As Float _
                ,originLatitudeUncertainty As Float _
                ,originAzimuthalGap As Float _
                ,magnitudeType As String _
                ,magnitudeValue As Float _
                ,magnitudeUncertainty As Float)
    Dim parser As SaxParser
    Dim ListOfEvents As List
    Dim currentEvent As Event
End Sub

Sub Globals

End Sub

Sub Activity_Create(FirstTime As Boolean)
    If FirstTime Then
        parser.Initialize
    End If
    ListOfEvents.Initialize
    Dim in As InputStream
    in = File.OpenInput(File.DirAssets, "data.xml")
    parser.Parse(in, "parser")
End Sub

Sub parser_StartElement (Uri As String, Name As String, Attributes As Attributes)
    If name = "event" Then
        Dim currentEvent As Event
        currentEvent.Initialize
        currentEvent.eventId = Attributes.GetValue2("", "publicID")
        ListOfEvents.Add(currentEvent)
    End If
End Sub

Sub parser_EndElement (Uri As String, Name As String, Text As StringBuilder)
    If parser.Parents.IndexOf("origin") > -1 Then
        Select Name
            Case "type"
                currentEvent.originType = Text.ToString
            Case "azimuthalGap"
                currentEvent.originAzimuthalGap = Text.ToString
        End Select
        If parser.Parents.IndexOf("latitude") > - 1 Then
            Select Name
                Case "value"
                    currentEvent.originLatitudeValue = Text.ToString
                Case "uncertainty"
                    currentEvent.originLatitudeUncertainty = Text.ToString
            End Select
        Else If parser.Parents.IndexOf("time") > -1 Then
            Select Name
                Case "value"
                    currentEvent.originTimeValue = Text.ToString
                Case "uncertainty"
                    currentEvent.originTimeUncertainty = Text.ToString
            End Select
        End If
    Else If parser.Parents.IndexOf("magnitude") > -1 Then
        Select Name
            Case "value"
                currentEvent.magnitudeValue = Text.ToString
            Case "uncertainty"
                currentEvent.magnitudeUncertainty = Text.ToString
            Case "type"
                currentEvent.magnitudeType = Text.ToString
        End Select
    Else 'main event nodes
        Select Name
            Case "type"
                currentEvent.eventType = Text.ToString
            Case "preferredOriginID"
                currentEvent.originId = Text.ToString
            Case "preferredMagnitudeID"
                currentEvent.magnitudeId = Text.ToString
        End Select
    End If
End Sub



[jscoulter]

Oh...thanks for that Erel. I wasnt expecting you to "do" anything :icon_clap:
I was getting carried away and having lists within lists you way is a LOT simpler than mental code thats for sure

So thanks again. Jeremy



[Inman]

The xmlsax library was working fine for me on this feed, until today. I now get "ExpatParser$ParseException". The reason is the 2nd item (currently) in the feed, titled - "LG Optimus Pro and Optimus Net go official, €180/€200 respectively". And the error is caused by the Euro(€) symbol.

Will you please take a look?



[Erel]

As the XML is not encoded with UTF8, you should create a TextReader with the correct encoding and then pass it to the parser.



[Inman]

Thanks for the tip. Took me a while to figure out. I originally tried to put the TextReader value back into the inputstream Finally I realised Parser has a Parser.Parse2() which accepts TextReader value itself. Works great now.



[MikieK]

Help

:sign0085:
Hi I am trying to make a music player that uses the phone's shared music preferences.
my code so far (minus the actual music playing) is:

'Activity module
Sub Process_Globals
   Dim parser As SaxParser
End Sub

Sub Globals
Dim seekpos As Long
Dim curpos As Int
Dim shufflemode As Int
Dim repeatmode As Int
Dim history As String
Dim queue As String
Dim historyflag As Boolean:historyflag = False
Dim queueflag As Boolean:queueflag = False
End Sub

Sub Activity_Create(FirstTime As Boolean)
   If FirstTime Then
      parser.Initialize
   End If
   'parse the xml file
   Dim in As TextReader
   in.Initialize(File.openinput("", "data/data/com.android.music/shared_prefs/Music.xml"))
   parser.Parse2(in, "Parser")
   in.Close
   Msgbox(history & CRLF & queue,"")
End Sub

Sub Parser_StartElement (Uri As String, Name As String, Attributes As Attributes)
   For i = 0 To Attributes.Size -1
      Select Attributes.GetValue(i)
         Case "seekpos"
            For i = 0 To Attributes.Size -1
               If Attributes.Getname(i) ="value" Then
                  seekpos = Attributes.GetValue(i)
                  Exit
               End If
            Next
         Case "curpos"
            For i = 0 To Attributes.Size -1
               If Attributes.Getname(i) ="value" Then
                  curpos = Attributes.GetValue(i)
                  Exit
               End If
            Next
         Case "shufflemode"
            For i = 0 To Attributes.Size -1
               If Attributes.Getname(i) ="value" Then
                  shufflemode = Attributes.GetValue(i)
                  Exit
               End If
            Next
         Case "repeatmode"
            For i = 0 To Attributes.Size -1
               If Attributes.Getname(i) ="value" Then
                  repeatmode = Attributes.GetValue(i)
                  Exit
               End If
            Next
         Case "history"
            historyflag = True
         Case "queue"
            queueflag = True
      End Select
   Next
End Sub

Sub Parser_EndElement (Uri As String, Name As String, Text As StringBuilder)
   If historyflag Then
      history = text.ToString
      historyflag = False
   End If
   If queueflag Then
      queue = text.ToString
      queueflag = False
   End If
End Sub

the Music.xml file looks like this:

<?xml version="1.0" encoding="UTF-8" standalone="true"?>
<map>
[INDENT]<string name="history">95;d01;dd;</string>
<string name="queue">6c;121;7c1;06;</string>
<int name="curpos" value="597"/>
<int name="cardid" value="808663139"/>
<int name="shufflemode" value="1"/>
<long name="seekpos" value="71524"/>
<int name="repeatmode" value="0"/> [/INDENT]
</map>

the issue i'm getting is instead of getting "6c;121;7c1;06;" in queue or "95;d01;dd;" in history, nothing is being returned. Any ideas?

Forgive my probably not very good coding I'm a :sign0104:



[Erel]

You can use Attributes.GetValue2("", "value") to get the value attribute instead of the inner loop (and Attributes.GetValue2("", "name") instead of the first For loop).

After applying these changes, I recommend you to run it with debugger attached and see which fields are found.



[MikieK]

Thanks

Hi Erel,
Firstly, I want to say thankyou for such a quick reply

Sub Parser_StartElement (Uri As String, Name As String, Attributes As Attributes)
         Select Attributes.GetValue2("", "name")
         Case "seekpos"
            seekpos = Attributes.GetValue2("", "value")
         Case "curpos"
            curpos = Attributes.GetValue2("", "value")
         Case "shufflemode"
            shufflemode = Attributes.GetValue2("", "value")
         Case "repeatmode"
            repeatmode = Attributes.GetValue2("", "value")
         Case "history"
            historyflag = True
         Case "queue"
            queueflag = True
      End Select
End Sub

Works a treat!
However, the issue doesn't really concern that. I have already played around with the debugger, I put a message box in the Parser_EndElement sub:

If historyflag Then
msgbox("","")
      history = text.ToString
      historyflag = False
   End If

I pressed pause when this was shown, after I pressed OK on the phone, the debugger showed that the text variable was empty, the uri variable was empty and the name variable contained "string".
I'm expecting that the string being returned will be very long (ie. refering to 4gigs of music files) could this be an issue?



[Erel]

Are you sure that there is text in the "history" node?
Can you upload your complete project and the XML file?



[MikieK]

My project

Firstly, you may or may not have the Music.xml file I'm reffering to, (I haven't made allowances for that yet), but here is my project and my Music.xml file from my phone.
Actually, just realised that there is no text in the history node, but I get the same problem for the queue node.



[Erel]

There is no text in the history node...



[MikieK]

:sign0013: try the queue node.



[Erel]

Works fine with the queue node.
