Android Tutorial Create dynamic jpg using b4a and php

Discussion in 'Tutorials & Examples' started by DonManfred, May 11, 2014.

  1. DonManfred

    DonManfred Expert Licensed User

    With this samplecode i will demonstrate to create a dynamic jpg from other image, put text´s on it, copy another image to it...

    ATTENTION: This b4a-example uses CreateMap so you need B4A V3.8 for it to work...

    The logic "in app" is simple.
    - A list with commands is created and send to php-script.
    - The php-script do all given commands in order to create respectively change an image.
    - The image is then written to disc and the url to this image is returned to the app.
    - The app see this url and download this image
    - After finished downloading the image it is showed up in a pictureviewer on the device.

    This is the Original

    This is the image after running the code

    Code:
    Dim cmds As List
    cmds.Initialize
    ' "init" should be the first action
    ' The image from imageurl is loaded as basis for the future actions
    cmds.Add(CreateMap("action""init""imageurl""http://pdf.basic4android.de/20140126_100310.jpg","type":"jpg"))
    '
    ' SetText writes a text into the pdf.
    ' border can be one OR more chars out of L, B, T, R (resp. Left, Bottom, Top, Right)
    ' x, y, w and h are the position and width/height of textbox
    ' r, g, b are the color for this text in RGB-format
    ' align can be L,C,R (leftjustify, center, rightjustify
    cmds.Add(CreateMap("action""SetText""text""Zora""angle"0,"x"650"y"700"r"255,"g"0,"b"0,"size"50,"font":"arial.ttf"))
    cmds.Add(CreateMap(
    "action""SetText""text""Lucky""angle"260,"x"700"y"210"r"255,"g"255,"b"255,"size"50,"font":"arial.ttf"))
    cmds.Add(CreateMap(
    "action""SetText""text""Charly""angle"30,"x"250"y"500"r"255,"g"255,"b"255,"size"50,"font":"arial.ttf"))
    '
    ' SetImage copy a image into the basis-image
    ' imgurl = url of the image
    ' dst_x and dst_y is the position in basis-image where the part of the image in imageurl
    ' at position src_x and src_y with the dimension src_w, src_h would be copied
    ' type can be jpg or png
    cmds.Add(CreateMap("action""SetImage""imageurl""http://www.basic4ppc.com/new_images/b4a_logo.png""dst_x"450"dst_y"550"src_x"0"src_y"0,"src_w"155,"src_h"84,"type":"png"))

    Dim json As JSONGenerator
    json.Initialize2(cmds)
    Log(json.ToString)
    Dim job As HttpJob
    Dim p As PhoneId
    job.Initialize(
    "createjpg", Me)
    job.download2(
    "http://pdf.basic4android.de/createimage.php"Array As String( _

    "json", json.ToString, _

    "DeviceID", p.GetDeviceId _
    ))
    Code:
    Sub JobDone(job As HttpJob)

    ProgressDialogHide

    If job.Success = True Then

    If job.JobName = "getimg" Then

    Dim OutStream As OutputStream

    Log("DownloadReady: "&job.Tag)
          OutStream =
    File.OpenOutput(File.DirRootExternal, job.Tag, False' Job.Tag is read to set the Original Filename we specify earlier in the creation of the Job
                File.Copy2(job.GetInputStream,OutStream) ' save the file
            OutStream.Close

    Log(job.Tag&" written to "&File.DirRootExternal) ' Write the Originalname to the log to see what happens ;-)


    'send the intent that asks the media scanner to scan the file
                Dim i As Intent
                i.Initialize(
    "android.intent.action.MEDIA_SCANNER_SCAN_FILE", _

    "file://" & File.Combine(File.DirRootExternal, job.Tag))

    Dim p As Phone
                p.SendBroadcastIntent(i)


    Dim i As Intent
              i.Initialize(i.ACTION_VIEW,
    "file://" & File.Combine(File.DirRootExternal, job.Tag))
              i.SetType(
    "image/*")

    StartActivity(i)

    'Dim i As Intent
                'i.Initialize(i.ACTION_VIEW, "file://" & File.Combine(File.DirRootExternal & "/", job.Tag))
                'i.SetComponent("android/com.android.internal.app.ResolverActivity")
                'i.SetType("application/pdf")
                'StartActivity(i)
            End If

    If job.JobName = "createjpg" Then

    Log(job.GetString)

    Dim parser As JSONParser
                parser.Initialize(job.GetString)

    Dim m As Map = parser.NextObject

    Dim img As String = m.Get("image")

    Dim resultcode As Int = m.Get("resultcode")

    If resultcode = 0 Then

    If img <> "" Then

    Dim job As HttpJob
                        job.Initialize(
    "getimg", Me)
                        job.Tag =
    "result.jpg"
                        job.download(img)

    End If

    End If

    End If

    Else

    Log("Error: " & job.ErrorMessage)

    End If
    End Sub


    Attached Files:

    Last edited: May 18, 2014
    fireday, eurojam, hibrid0 and 6 others like this.
  2. DonManfred

    DonManfred Expert Licensed User

    Here another example

    Code:
    Dim cards As List
        cards.Initialize
        cards.Add(
    "ace")
        cards.Add(
    "2")
        cards.Add(
    "3")
        cards.Add(
    "4")
        cards.Add(
    "5")
        cards.Add(
    "6")
        cards.Add(
    "7")
        cards.Add(
    "8")
        cards.Add(
    "9")
        cards.Add(
    "10")
        cards.Add(
    "J")
        cards.Add(
    "Q")
        cards.Add(
    "K")



    Dim cmds As List
        cmds.Initialize

    ' "init" should be the first action
        ' The image from imageurl is loaded as basis for the future actions
        cmds.Add(CreateMap("action""init""imageurl""http://pdf.basic4android.de/decks/classic-playing-cards.png","type":"png","destinationname":"card"))


    Dim rowx,rowy As Int


    ' Row 1 - clubs
        rowy = 0

    For i = 0 To cards.Size-1
            cmds.Add(CreateMap(
    "action""copy2jpg""name""clubs-"&cards.Get(i), "x": (i*60), "y": rowy, "w"60,"h":80))

    Next

    ' Row 2 - spade
        rowy = 80

    For i = 0 To cards.Size-1
            cmds.Add(CreateMap(
    "action""copy2jpg""name""spade-"&cards.Get(i), "x": (i*60), "y": rowy, "w"60,"h":80))

    Next

    ' Row 1 - clubs
        rowy = 160

    For i = 0 To cards.Size-1
            cmds.Add(CreateMap(
    "action""copy2jpg""name""heart-"&cards.Get(i), "x": (i*60), "y": rowy, "w"60,"h":80))

    Next

    ' Row 1 - clubs
        rowy = 240

    For i = 0 To cards.Size-1
            cmds.Add(CreateMap(
    "action""copy2jpg""name""diamond-"&cards.Get(i), "x": (i*60), "y": rowy, "w"60,"h":80))

    Next


    Dim json As JSONGenerator
        json.Initialize2(cmds)

    Log(json.ToString)

    Dim job As HttpJob

    Dim p As PhoneId
        job.Initialize(
    "createjpg", Me)
        job.download2(
    "http://pdf.basic4android.de/createimage.php"Array As String( _

    "json", json.ToString, _

    "DeviceID", p.GetDeviceId _
        ))
    Code:
    Sub JobDone(job As HttpJob)

    ProgressDialogHide

    If job.Success = True Then

    If job.JobName = "getimg" Then

    Dim OutStream As OutputStream

    Log("DownloadReady: "&job.Tag)
          OutStream =
    File.OpenOutput(File.DirRootExternal, job.Tag, False' Job.Tag is read to set the Original Filename we specify earlier in the creation of the Job
                File.Copy2(job.GetInputStream,OutStream) ' save the file
            OutStream.Close

    Log(job.Tag&" written to "&File.DirRootExternal) ' Write the Originalname to the log to see what happens ;-)


    'send the intent that asks the media scanner to scan the file
                Dim i As Intent
                i.Initialize(
    "android.intent.action.MEDIA_SCANNER_SCAN_FILE", _

    "file://" & File.Combine(File.DirRootExternal, job.Tag))

    Dim p As Phone
                p.SendBroadcastIntent(i)


    Dim i As Intent
              i.Initialize(i.ACTION_VIEW,
    "file://" & File.Combine(File.DirRootExternal, job.Tag))
              i.SetType(
    "image/*")

    StartActivity(i)

    'Dim i As Intent
                'i.Initialize(i.ACTION_VIEW, "file://" & File.Combine(File.DirRootExternal & "/", job.Tag))
                'i.SetComponent("android/com.android.internal.app.ResolverActivity")
                'i.SetType("application/pdf")
                'StartActivity(i)
            End If

    If job.JobName = "getimg2" Then

    Dim OutStream As OutputStream

    Log("DownloadReady: "&job.Tag)
          OutStream =
    File.OpenOutput(File.DirRootExternal, job.Tag, False' Job.Tag is read to set the Original Filename we specify earlier in the creation of the Job
                File.Copy2(job.GetInputStream,OutStream) ' save the file
            OutStream.Close

    Log(job.Tag&" written to "&File.DirRootExternal) ' Write the Originalname to the log to see what happens ;-)


    'send the intent that asks the media scanner to scan the file
                Dim i As Intent
                i.Initialize(
    "android.intent.action.MEDIA_SCANNER_SCAN_FILE", _

    "file://" & File.Combine(File.DirRootExternal, job.Tag))

    Dim p As Phone
                p.SendBroadcastIntent(i)

    End If

    If job.JobName = "createjpg" Then

    Log(job.GetString)


    Dim parser As JSONParser
                parser.Initialize(job.GetString)

    Dim m As Map = parser.NextObject

    Dim img As String = m.Get("image")

    Dim resultcode As Int = m.Get("resultcode")

    If resultcode = 0 Then

    Dim newimages As List = m.Get("newimages")

    For Each colnewimages As String In newimages

    If colnewimages <> "" Then

    Dim job As HttpJob
                            job.Initialize(
    "getimg2", Me)
                            job.Tag = GetFilename(colnewimages)
                            job.download(colnewimages)

    End If


    Next


    End If

    End If

    Else

    Log("Error: " & job.ErrorMessage)

    End If
    End Sub
    Sub GetFilename(fullpath As StringAs String

    Return fullpath.SubString(fullpath.LastIndexOf("/") + 1)
    End Sub
    This is the "starting-image"
    [​IMG]

    The created single Card-images you find in Cards.zip

    Please note that you need an updated php-script. V1.1 of php-script is updated in Post #1


    Attached Files:

    Kwame Twum, fireday, hibrid0 and 5 others like this.
